Name: SMT Pick And Place Machines NPM-GW Modular Placement Machine
Brand: Global Soul Limited
SKU: NPM-GW
Availability: InStock

Home > products > SMT Placement Machine >

SMT Pick And Place Machines NPM-GW Modular Placement Machine

Place of Origin:

Japan

Brand Name:

Panasonic

Model Number:

NPM-GW

Request A Quote

Product Details

Placement Accuracy (Cpk≥1):

±25μm/chip

Max.speed (per 1 Head):

52000 Cph(0.070s/chip)

Maximum PCB Dimensions(For Single Conveyor):

L760×W 687 Mm※Slide Mounting:1,050 Mm/1,260 Mm

Component Dimensions(mm):

0201chip～L120×W90×T40/T45 Or L150×W25×T40/T 45

PCB Transfer Lane:

Single/Dual

Component Supply:

Taping/Stick/Tray

Maximum Number Of Components Supply(Tape Width:4 Mm,8 Mm Calculation):

136

Number Of Heads:

Placement Heads:

16/8/3

Condition:

Used Original

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

2000*800*1200mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

SMT Pick And Place Machines Sony SI-F209

Get Best Price

Video

SMT Pick And Place Machines NPM-GW Modular Placement Machine

Get Best Price

Video

3 Phase AC 200V SMT Pick And Place Machines Panasonic RG131 NM-EJR3A NM-EJR4A

Get Best Price

Video

Chip Capacitor Resistor X-ray Counter Machine DS3000 with 800W Aggregate Capacity

Get Best Price

86-0755-27678283

Contact Now

Product Description

Key features and functions
1. Support large components and large PCBs to meet the increasing demand for Electric Vehicles (EV) and DX
2. 5M process control “APC-5M” for good production and stable operation
3. Various skill-less and manpower-saving features including Auto Setting Feeder
* 5M: The variable elements of a production site: huMan, Machine, Material, Method, and Measurement

Panasonic Modular Placement Machine NPM-GW Features

Modular mounter with wide range of components/PCBs compatibility

The basic performance of this modular mounter has been improved by renewing the core units, such as the placement head and recognition camera. It now supports a wide range of components and various components supply configurations, and can also handle larger PCBs. It also supports various automation and manpower-saving functions, including the Auto Setting Feeder (ASF), which automates the components supply operation, to flexibly meet the requirements of each mounting site.

Supported components range

SMT Pick And Place Machines NPM-GW Modular Placement Machine 0

Maximum speed and placement accuracy

SMT Pick And Place Machines NPM-GW Modular Placement Machine 1

Supported PCB size

SMT Pick And Place Machines NPM-GW Modular Placement Machine 2

Configuration example

SMT Pick And Place Machines NPM-GW Modular Placement Machine 3

Example configuration

SMT Pick And Place Machines NPM-GW Modular Placement Machine 4

Component supply units

SMT Pick And Place Machines NPM-GW Modular Placement Machine 5

SMT Pick And Place Machines NPM-GW Modular Placement Machine 6
