Name: Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning
Brand: Global Soul Limited
SKU: RL-8100
Availability: InStock

Home > Products > SMT Placement Machine >

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Electric Steel Mesh Cleaning Machine

Mesh Cleaning Machine 25KW

Place of Origin:

China

Brand Name:

Model Number:

RL-8100

Document:

Product Brochure PDF

Request A Quote

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Product Details

Applicable Steel Mesh Size:

L750 × W750 × H40(mm) [large Size Needs To Be Customized]

Equipment Dimensions:

L1220*W1120*H1850 (mm)

Maximum Volume Of Liquid Tank:

50L*2PCS

Optimal Liquid Usage:

40L*2PCS

Cleaning, Rinsing, Drying Method:

Left And Right Mobile High Pressure Spray Cleaning + High Pressure Hot Air Cutting (optional Super Model)

Cleaning Solution Isolation Time:

40 To 60S

Cleaning Time:

2-5min

Drying Time:

2-5min

Filtration System (Level 1):

Level 1 Filter Element Filtration: (Filter Impurities And Labels)

Filtration System (secondary):

Secondary Filter Filter: (filter Solder Paste And Rosin Particles)

Cleaning Liquid Recovery Filter (Level 3):

1μm (Filter Particles: Solder Paste, Rosin, Red Glue And Pollutants)

Rinse Liquid Discharge Filtration (Level 3):

5μm (filter Particles: Solder Paste, Rosin, Red Glue And Pollutants) Solution

Body Heating Temperature:

Room Temperature ~ 60℃ (temperature Can Be Set)

Electric External Air Source:

0.4 ~ 0.6 (Mpa)

Water Pressure:

0.2 ~ 0.3(Mpa)

Exhaust Port Size:

Φ125×H25(mm)

Power Supply:

AC380V 50HZ

The Total Power:

25KW

Net Weight:

About 580Kg

Condition:

Original New

Highlight:

Electric Steel Mesh Cleaning Machine

Mesh Cleaning Machine 25KW

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1400*1350*2000mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

Electric Steel Mesh Cleaning Machine 25KW

Machine Characteristics

High-pressure spray system specifically designed for water-based cleaning of screen boards, misprint boards, and printing machine scrapers
Dual liquid tank configuration with integrated heating system for comprehensive cleaning, rinsing, and hot air drying
Complete stainless steel construction for durability and resistance to acidic and alkaline cleaning fluids
Advanced touch screen operating software with program file saving and simplified operation
System counting function automatically tracks cleaning board quantities and cycle filtering operations
Real-time pressure monitoring through panel gauges with sensor-based pressure alerts
Direct liquid reflux system significantly reduces cleaning fluid consumption
High-pressure fan combined with hot air drying for faster, more thorough drying results

Cleaning Process Flow

Cleaning → Chemical Isolation → Rough Rinsing (Open/Closed Loop) → Fine Rinsing (Open/Closed Loop) → Drying

Operational Efficiency

Cost-Effective Operation: Each cleaning cycle consumes only 30-120ml of cleaning fluid. The system utilizes compressed air to recover residual liquid from pipelines and pumps, reducing overall fluid consumption by up to 50%.

Advanced Monitoring: Liquid levels and pump pressure are continuously displayed through panel pressure gauges, providing immediate feedback on equipment operating status.

Technical Specifications

Power Rating	25KW
Construction Material	Full Stainless Steel Body
Tank Configuration	Dual Liquid Tank System
Fluid Consumption	30-120ml per Cleaning Cycle
Drying System	High-Pressure Fan with Hot Air Drying

Industry Applications
