High-Speed Yamaha YSM20R SMT Pick And Place Machine with Dual-Stage Conveyor and Advanced Vision System

Product Details

Model:

YSM20R

Single Lane:

L810 X W490 To L50 X W50

Dual Stage Note:

For X-axis 2-beam Option Only

1PCB Conveyance:

L810 X W490 To L50 X W50

2PCB Conveyance:

L380 X W490 To L50 X W50

Mounting Accuracy:

±0.035mm (±0.025mm) Cpk≧1.0 (3σ)

High-Speed Multi (HM) Head NOTE:

0201 To W55 X L100mm (Indexing Recognition Exceeding W45mm), Height 15mm Or Less

Note:

Component Height Of 6.5mm Or Higher Or Components Sizes Of 12mm In In Length/width Or Greater Requires Optional Multi Camera. Please Contact Us For Info Regarding Mounting 0201 Components

Odd-shaped Components (FM: Flexible Multi) Head:

03015 To W55 X L100mm (indexing Recognitions Exceeding W45mm), Height 28mm Or Less

Fixed Plate:

140 Types (conversion For 8mm Tape Feeder)

Feeder Carriage Exchange:

Max 128 Types (conversion For 8mm Tape Feeder)

Power Supply:

3-phase AC 200/208/220/240/380/400/416 V ±10 % 50/60Hz

Air Supply Source:

Clean Dry Air Of 0.45 MPa Or More

External Dimension:

L1,374 X W1,857 X H1,445mm

Weight:

Approx 2050kg

Highlight:

High Speed SMT Pick And Place Machines

YAMAHA SMT Pick And Place Machines

SMT High Speed Pick And Place Machine

Payment & Shipping Terms

Minimum Order Quantity

1 pcs

Price

USD+negotiable+pcs

Packaging Details

2000*2100*1800mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

High Speed YAMAHA SMT Pick And Place Machines Used Original YSM20R

Yamaha YSM20R Overview

The Yamaha YSM20R is a high-speed, versatile SMT (Surface Mount Technology) machine designed for efficient electronic component placement in demanding manufacturing environments.

Key Functions

High-Speed Placement: Capable of rapid component placement to maximize production throughput
Multi-Functional Capability: Handles a wide range of components for various production requirements
Advanced Vision System: Ensures precise alignment and accurate placement of components

Machine Features

Dual-Stage Conveyor: Allows simultaneous processing of multiple PCBs, enhancing efficiency
Flexible Configuration: Supports different board sizes and component types for production adaptability
User-Friendly Interface: Intuitive controls and software for easy operation and quick setup
Precision Control: High accuracy in component placement reduces errors and improves quality

Industrial Applications

Ideal for industries such as consumer electronics, telecommunications, and automotive electronics where speed and precision are essential for high-volume production.

Performance Summary

The Yamaha YSM20R combines exceptional speed, operational flexibility, and placement precision, making it a valuable asset for optimizing SMT assembly processes and enhancing manufacturing efficiency.
