Name: SONY SI-F130 SMT Pick And Place Machine with 25900 CPH Speed, Optical Recognition System, and Planetary Type Mounting Head
Brand: Global Soul Limited
SKU: SI-F130
Availability: InStock

Home > Products > SMT Placement Machine >

SONY SI-F130 SMT Pick And Place Machine with 25900 CPH Speed, Optical Recognition System, and Planetary Type Mounting Head

25900 CPH SMT Pick And Place Machine

Optical Recognition System SMT Placement Machine

Planetary Type Mounting Head Surface Mounter

Place of Origin:

Japan

Brand Name:

SONY

Model Number:

SI-F130

Document:

Product Brochure PDF

Request A Quote

Product Details

Equipment Model:

SI-F130

Soldering Head:

1 Head & 12 Nozzles

Feeder Quantity:

Vision System:

Optical Recognition System

Component Size:

Max: 6mm

Soldering Accuracy:

50um (CPK 1.0 Or Above)

PCB Size:

50mm*50mm - 360mm*1200mm

Component Thickness:

0402 (01005) - 12mm IC (mobile Camera) 6mm - 25mm IC (fixed Camera)

PCB Thickness:

0.5mm To 2.6mm

Operating Environment:

Ambient Temperature 15℃~30℃, Environmental Humidity 30%~70% (no Condensation Allowed)

Working Noise:

35-65 Decibels

Correction Method:

Machine Vision System, Multi-point MARK Vision Correction

Drive System:

AC Servo, AC Motor

Data Transmission:

USB Interface Input (EXCEL Document Format)

Operating System:

Chinese, English, Japanese Interface (WINDOWS System Control Platform)

Control Mode:

Fully Automatic

Soldering Speed:

0.139 Seconds (25900 CPH)

Equipment Dimensions (W*D*H):

1220mm X 1400mm X 1545mm

Equipment Weight:

1560KG

Highlight:

25900 CPH SMT Pick And Place Machine

Optical Recognition System SMT Placement Machine

Planetary Type Mounting Head Surface Mounter

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1500mm*1600mm*1750mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

SONY SI-F130 SMT Pick And Place Machine

The SONY SI-F130 SMT Pick and Place Machine represents the pinnacle of surface mount technology, delivering exceptional performance and reliability for modern manufacturing environments.

Equipment Overview

The SONY 130 series surface mounters are available in three distinct models: F130, F130AI, and F130WK. These classic models are renowned for their superior quality construction and advanced technological features.

Key Performance Features

High-Speed Operation: Achieves 25,900 CPH (0.139 seconds per chip)
Advanced Vision System: Utilizes CCD camera with unique image recognition technology
Planetary Mounting Head: Globally unique rotating planetary design with 12 suction nozzles
Superior Accuracy: Precise component placement with high mounting accuracy
Optimized Footprint: Compact design with low power and air consumption
Quiet Operation: Low noise levels for improved working environment

Industry-Leading Technology: The planetary-type mounting head design provides unmatched speed and precision, significantly enhancing actual production efficiency for demanding manufacturing applications.

Application Specialization

Specifically engineered for high-speed surface mounting of 1.2-meter LED light beads, making it the ideal solution for LED lighting manufacturing and similar precision assembly requirements.

Operational Advantages: Small footprint, reduced energy consumption, minimal air usage, and quiet operation combine to create an efficient and cost-effective manufacturing solution.
