Name: Momentum II HiE Stencil Printer with Servo Motors for High Throughput and 609.6 mm x 508 mm Print Area
Brand: Global Soul Limited
SKU: Momentum II HiE
Availability: InStock

Home > Products > SMT Placement Machine >

Momentum II HiE Stencil Printer with Servo Motors for High Throughput and 609.6 mm x 508 mm Print Area

Momentum II HiE Stencil Printer

High Throughput Stencil Printer

Single-rail Stencil Printer

Brand Name:

ITW EAE

Model Number:

Momentum II HiE

Document:

Product Brochure PDF

Request A Quote

Momentum II HiE Stencil Printer with Servo Motors for High Throughput and 609.6 mm x 508 mm Print Area

Product Details

Maximum Board Size (X X Y):

609.6 Mm X 508 Mm (24” X 20”)

Staging Mode - Momentum II Elite:

457 Mm X 508 Mm (18” X 20”)A Dedicated Workholder Is Required For Boards With An X Size Greater Than 20”

Minimum Board Size (X X Y):

50.8 Mm X 50.8 Mm (2” X 2”)

Board Thickness:

0.2mm (0.008”) To 5.0mm (0.20”), Up To 6.0 Mm (0.24”) Without Top Clamp Foils

Maximum Board Weight:

4.5 Kg (10 Lbs)

Board Edge Clearance:

3.0 Mm (0.118")

Underside Clearance:

12.7 Mm (0.5") Standard Configurable For 25.4 Mm (1.0”)

Board Hold-Down:

EdgeLoc II, Centernest Vacuum；Optional: Fixed Top Clamps, EdgeLoc+

Board Support Methods:

Magnetic Pins；Optional: Vacuum Side Dams, Vacuum Pins, Support Blocks, Dedicated Fixtures, Patented Auto Tooling, Quik-Tool

PRINT PARAMETERS Maximum Print Area (X X Y):

609.6 Mm X 508 Mm (24” X 20")

Print Gap (Snap-off):

0 Mm To 6.35 Mm (0" To 0.25")

Print Speed:

Up To 305 Mm/sec (12.0”/sec)

Print Force:

0 To 20 Kg (0 Lb To 44 Lbs)

Stencil Frame Size:

737 Mm X 737 Mm (29" X 29")；Adapters Available For Smaller Sizes

Vision Field-of-View (FOV):

10.6 Mm X 8.0 Mm (0.417” X 0.315”)

Fiducial Types:

Standard Shape Fiducials (see SMEMA Standards), Pad/aperture

Camera System:

Single Digital Camera ；MPM Patented Look Up/down Vision

Machine Width Momentum II HiE:

1203.0 Mm (47.4”)

Minimum Front Clearance:

508 Mm (20.0”)

Minimum Rear Clearance:

508 Mm (20.0”)

Machine Weight Momentum II HiE:

862 Kg (1900 Lbs)

Momentum II HiE:

1155.5 Kg (2547 Lbs)

Highlight:

Momentum II HiE Stencil Printer

High Throughput Stencil Printer

Single-rail Stencil Printer

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1700*1350*1600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

Momentum II HiE Stencil Printer Single-Rail with Servo Motors

The MPM Momentum II stencil printer is a proven, highly productive platform delivering industry-leading accuracy and repeatability, certified by third-party validation. Enhanced technologies provide significant improvements in machine productivity, yield, ease of use, and operational flexibility.

High-Efficiency Single-Rail Design

The Momentum II HiE features a single-rail configuration with servo motors driving the vision system's X, Y, and Z axes. Unlike traditional stepper motors, servos operate at higher speeds, enabling faster vision gantry movement that increases throughput and reduces cycle times for efficient high-volume printing operations.

Advanced Performance Features

Rigid Welded Frame: Engineered for minimal vibrations with precision ball screw-driven major assemblies

Enhanced Repeatability: Superior reliability and consistent performance over extended operation

Advanced Print Head: High-precision load cell with closed-loop pressure control for precise squeegee force

Tighter Performance Tolerances: Ensures consistent repeatability with higher production yield

The Momentum II stencil printers are specifically engineered for high-throughput applications requiring exceptional accuracy, making them ideal for demanding electronic manufacturing environments.

Operational Benefits

New features and enhancements enable measurable improvements in productivity, yield, operational versatility, and ease of use, ensuring optimal performance in high-volume production settings.
