Name: Momentum II Elite Stencil Printer with 10.6 mm x 8.0 mm Vision FOV 12.7 mm Underside Clearance and 609.6 mm x 508 mm Maximum Board Size
Brand: Global Soul Limited
SKU: Momentum II Elite
Availability: InStock

Home > Products > SMT Placement Machine >

Momentum II Elite Stencil Printer with 10.6 mm x 8.0 mm Vision FOV 12.7 mm Underside Clearance and 609.6 mm x 508 mm Maximum Board Size

Innovative Momentum II Elite Stencil Printer

12.7 mm Underside Clearance Stencil Printer

Brand Name:

ITW EAE

Model Number:

Momentum II Elite

Document:

Product Brochure PDF

Request A Quote

Momentum II Elite Stencil Printer with 10.6 mm x 8.0 mm Vision FOV 12.7 mm Underside Clearance and 609.6 mm x 508 mm Maximum Board Size

Product Details

Maximum Board Size (X X Y):

609.6 Mm X 508 Mm (24” X 20”)

Staging Mode - Momentum II Elite:

457 Mm X 508 Mm (18” X 20”)A Dedicated Workholder Is Required For Boards With An X Size Greater Than 20”

Minimum Board Size (X X Y):

50.8 Mm X 50.8 Mm (2” X 2”)

Board Thickness:

0.2mm (0.008”) To 5.0mm (0.20”), Up To 6.0 Mm (0.24”) Without Top Clamp Foils

Maximum Board Weight:

4.5 Kg (10 Lbs)

Board Edge Clearance:

3.0 Mm (0.118")

Underside Clearance:

12.7 Mm (0.5") Standard Configurable For 25.4 Mm (1.0”)

Board Hold-Down:

EdgeLoc II, Centernest Vacuum；Optional: Fixed Top Clamps, EdgeLoc+

Board Support Methods:

Magnetic Pins；Optional: Vacuum Side Dams, Vacuum Pins, Support Blocks, Dedicated Fixtures, Patented Auto Tooling, Quik-Tool

PRINT PARAMETERS Maximum Print Area (X X Y):

609.6 Mm X 508 Mm (24” X 20")

Print Gap (Snap-off):

0 Mm To 6.35 Mm (0" To 0.25")

Print Speed:

Up To 305 Mm/sec (12.0”/sec)

Print Force:

0 To 20 Kg (0 Lb To 44 Lbs)

Stencil Frame Size:

737 Mm X 737 Mm (29" X 29")；Adapters Available For Smaller Sizes

Vision Field-of-View (FOV):

10.6 Mm X 8.0 Mm (0.417” X 0.315”)

Fiducial Types:

Standard Shape Fiducials (see SMEMA Standards), Pad/aperture

Camera System:

Single Digital Camera ；MPM Patented Look Up/down Vision

Machine Width Momentum II Elite:

1675.5 Mm (66.0”)

Minimum Rear Clearance:

508 Mm (20.0”)

Momentum II Elite:

1192.5 Kg (2629 Lbs)

Highlight:

Innovative Momentum II Elite Stencil Printer

12.7 mm Underside Clearance Stencil Printer

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1700*1800*1600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

Innovative Momentum II Elite Stencil Printer 10.6 mm x 8.0 mm Vision FOV and 12.7 mm Underside Clearance

Enhanced Features & Capabilities

The Momentum II Elite Stencil Printer incorporates advanced features designed to maximize productivity and precision in electronic assembly applications.

Newly designed cover set with larger window and wider internal access for improved visibility and maintenance
Adjustable stencil shelf providing flexibility for handling diverse board varieties
EdgeLoc II and EdgeLoc+ systems for precise board clamping and positioning
Advanced jar paste dispenser for increased throughput and productivity
Solder paste roll height monitoring for yield optimization and process traceability
Solder paste temperature monitoring for enhanced yield and quality control
Quick release squeegee mechanism for faster changeover and reduced downtime
Upgraded Benchmark GUI with customizable production interface and Quickstart program functionality
Windows 10 operating system for modern computing platform support

Technical Specifications

Vision Field of View: 10.6 mm x 8.0 mm | Underside Clearance: 12.7 mm
