Name: Innovative Momentum II Elite Stencil Printer 10.6 mm x 8.0 mm Vision FOV and 12.7 mm Underside Clearance
Brand: Global Soul Limited
SKU: Momentum II Elite
Availability: InStock

Home > products > SMT Placement Machine >

Innovative Momentum II Elite Stencil Printer 10.6 mm x 8.0 mm Vision FOV and 12.7 mm Underside Clearance

Innovative Momentum II Elite Stencil Printer

12.7 mm Underside Clearance Stencil Printer

Brand Name:

ITW EAE

Model Number:

Momentum II Elite

Request A Quote

Product Details

Maximum Board Size (X X Y):

609.6 Mm X 508 Mm (24” X 20”)

Staging Mode - Momentum II Elite:

457 Mm X 508 Mm (18” X 20”)A Dedicated Workholder Is Required For Boards With An X Size Greater Than 20”

Minimum Board Size (X X Y):

50.8 Mm X 50.8 Mm (2” X 2”)

Board Thickness:

0.2mm (0.008”) To 5.0mm (0.20”), Up To 6.0 Mm (0.24”) Without Top Clamp Foils

Maximum Board Weight:

4.5 Kg (10 Lbs)

Board Edge Clearance:

3.0 Mm (0.118")

Underside Clearance:

12.7 Mm (0.5") Standard Configurable For 25.4 Mm (1.0”)

Board Hold-Down:

EdgeLoc II, Centernest Vacuum；Optional: Fixed Top Clamps, EdgeLoc+

Board Support Methods:

Magnetic Pins；Optional: Vacuum Side Dams, Vacuum Pins, Support Blocks, Dedicated Fixtures, Patented Auto Tooling, Quik-Tool

PRINT PARAMETERS Maximum Print Area (X X Y):

609.6 Mm X 508 Mm (24” X 20")

Print Gap (Snap-off):

0 Mm To 6.35 Mm (0" To 0.25")

Print Speed:

Up To 305 Mm/sec (12.0”/sec)

Print Force:

0 To 20 Kg (0 Lb To 44 Lbs)

Stencil Frame Size:

737 Mm X 737 Mm (29" X 29")；Adapters Available For Smaller Sizes

Vision Field-of-View (FOV):

10.6 Mm X 8.0 Mm (0.417” X 0.315”)

Fiducial Types:

Standard Shape Fiducials (see SMEMA Standards), Pad/aperture

Camera System:

Single Digital Camera ；MPM Patented Look Up/down Vision

Machine Width Momentum II Elite:

1675.5 Mm (66.0”)

Minimum Rear Clearance:

508 Mm (20.0”)

Momentum II Elite:

1192.5 Kg (2629 Lbs)

Highlight:

Innovative Momentum II Elite Stencil Printer

12.7 mm Underside Clearance Stencil Printer

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1700*1800*1600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

High Speed YAMAHA SMT Pick And Place Machines Used Original YSM20R

Get Best Price

YS12F Used Origianl YAMAHA SMT Pick And Place Machines KKJ-000

Get Best Price

Used Original Yamaha YCP10 SMT Electronics Pick And Place Machine

Get Best Price

NM-EJM6E SMT Pick And Place Machines Used original Panasonic NPM-D3A Machine

Get Best Price

86-0755-27678283

Contact Now

Product Description

Momentum@ lI New Features
1. Newly designed cover set with larger window and wider access inside the printer.
2. Adjustable stencil shelf for flexibility handling board varieties.
3. EdgeLoc II and EdgeLoc+ precise board clamping.
4. New jar paste dispenser for increased productivity.
5. Solder paste roll height monitoring for yield improvement and traceability.
6. Solder paste temperature monitoring for yield improvement and traceability.
7. Quick release squeegee for faster changeover.
8. Upgraded Benchmark GUI with customizable production page and Quickstart program.
9. Windows 10 operating system.

Innovative Momentum II Elite Stencil Printer 10.6 mm x 8.0 mm Vision FOV and 12.7 mm Underside Clearance 0
