Name: High Precision 3D-AOI PCBA Testing Equipment for 0.6-6mm Thickness and Turn Over Parts Detection
Brand: Global Soul Limited
SKU: SI-1030E
Availability: InStock

Home > Products > SMT Placement Machine >

High Precision 3D-AOI PCBA Testing Equipment for 0.6-6mm Thickness and Turn Over Parts Detection

3D-AOI PCBA Testing Equipment

0.6-6mm PCBA Testing Equipment

High Precision PCBA Testing Equipment

Place of Origin:

China

Brand Name:

Sailyond

Model Number:

SI-1030E

Document:

Product Brochure PDF

Request A Quote

High Precision 3D-AOI PCBA Testing Equipment for 0.6-6mm Thickness and Turn Over Parts Detection

Product Details

Size:

50×50mm~460×510mm

Thickness:

0.6-6mm (H)

Top:

1200w Color Industrial Camera

Bottom:

40mm

Process Side:

>=3mm

Component Defects:

Missing Parts, Offset, Skew, Stele, Side Stand, Turn Over Parts, Wrong Parts, Damage, Reverse, Component Height Measurement, Warping

Solder Paste Defects:

More Tin, Less Tin, Tin, Tin Ball, Virtual Welding, Missing Welding Component Positioning/Component Type/component Composition Area (package/pad)/ Character Recognition

All Around:

Angle Camera.AOI Four-color Integrating Sphere Light Source, Coaxial Light Stripe Structure Light

Resolution:

10um

Main Reference Size (mm):

1280*1680*1580(W*H*D)

Reference Weight:

About 900kg

Gas Supply:

0.4-0.7Mpa (pure Electricity Optional)

Power Supply:

AC 220v

Replacement Capacity:

Rapid Replacement Of Equipment, Replacement Time <=1h/ Person/unit

Highlight:

3D-AOI PCBA Testing Equipment

0.6-6mm PCBA Testing Equipment

High Precision PCBA Testing Equipment

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1350*1780*1680mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

High Precision 3D-AOI PCBA Testing Equipment SI-1030E

Advanced Detection Capabilities

Designed for turn over parts component defects detection
Handles component thickness range: 0.6-6mm
Strong generalization with high detection rate and low false alarm rate
False detection rate less than 1% with reliable AI technology

Connectivity & System Integration

End-to-end cloud connectivity with remote management support
Full MES system compatibility
Supports offline operation and online non-stop debugging
Zero missing report capability

AI-Powered Performance

40+ cutting-edge AI model strategies for efficient and accurate detection
1 millisecond algorithm inference with greatly improved speed
Extremely optimized model algorithms
Effectively reduces algorithm misjudgment

Intelligent Programming & Operation

Programming time less than 1 minute
No component library required - true one-click programming
Does not rely on device library
Completes intelligent detection of devices
Recognizes devices not included in CAD (Device Location Information)

Advanced AI Learning Capabilities

Efficient learning of global characteristics of devices and defects
Intelligent generation of decision indicators for different devices, detection areas, and defect types
Normalization of multiple complex thresholds into tolerance threshold adjustments
No need to describe and define device details
Quantitative threshold adjustment suggestions through statistical data study

Operational Efficiency

No excessive technical requirements for programming personnel
Replacements can work at any time with minimal training
