Relentless All-Terrain SMT Dispensing Machine with 720’000 Dots/h Jet Valve and Curve Dispensing Mode for ±40 μm Accuracy

720'000 Dots/h Jet Valve Dispenser

Relentless All-Terrain Dispenser

Place of Origin:

Germany

Brand Name:

ESSEMTEC

Document:

Product Brochure PDF

Request A Quote

Relentless All-Terrain SMT Dispensing Machine with 720’000 Dots/h Jet Valve and Curve Dispensing Mode for ±40 μm Accuracy

Product Details

Piezo Jet Valve:

> 720’000 Dots/h

Dynamic Shockwave Valve:

720‘000 Dots/h

Time/Pressure Valve:

26‘000 Dots/h

Archimedean Screw Valve:

22‘000 Dots/h

Dispensing Mode:

Dot, Line, Curve, Interpolated 3D Contour

Accuracy Placement XY Dots:

±40 μm (3σ)

Accuracy Positioning Z Axis:

±20 μm (3σ)

PCB Dimensions:

560 X 610 Mm (22 X 24“)

Dimensions Machine Footprint:

1’557 X 1’357 Mm (61 X 53“)

Condition:

Original New/Used Original

Highlight:

720'000 Dots/h Jet Valve Dispenser

Relentless All-Terrain Dispenser

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1600*1500*1450mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

Relentless All-Terrain Dispenser with Curve Dispensing Mode and 720,000 Dots/h Jet Valve

Introducing The Tarantula

State-of-the-art dispensing technology designed for seamless integration into any production line. The Tarantula delivers exceptional performance across a comprehensive range of industrial applications.

Versatile Application Capabilities

Solder Paste & SMT Glue - Precision dispensing for surface mount technology
LED Encapsulation - Reliable protection and sealing for LED components
Silver Epoxy - Conductive adhesive applications with pinpoint accuracy
Dam and Fill - Advanced containment and filling operations
Underfill & Cavity Fill - Comprehensive filling solutions for complex geometries
3D Dispensing - Advanced laser height mapping for three-dimensional applications
