High Speed SMT Screen Printer and Pick and Place Machine with ±5.0 µm Repeatability and PC Board Edge Support

High Speed SMT Screen Printer and Pick and Place Machine with ±5.0 µm Repeatability and PC Board Edge Support

Pick Place Machine SP70

Pick Place Machine NM-EJP3A

High Speed SMT Screen Printer

Place of Origin:

Japan

Brand Name:

Panasonic

Model Number:

SP70 / NM-EJP3A

Document:

Product Brochure PDF

Contact Us
Request A Quote
High Speed SMT Screen Printer and Pick and Place Machine with ±5.0 µm Repeatability and PC Board Edge Support
High Speed SMT Screen Printer and Pick and Place Machine with ±5.0 µm Repeatability and PC Board Edge Support
Product Details
Model ID:
SP70
Model No:
NM-EJP3A
PCB Dimensions (mm):
L 50 × W 50 To L 510 × W 460 *1
Cycle Time:
5.2 S + Printing Time ( Board Size : 330 × 250 Mm)
Printing Accuracy:
±20 µm
Repeatability:
±5.0 µm
Screen Frame Dimensions (mm):
L 736 × W 736;L 650 × W 550 , L 600 × W 550
Electric Source:
3-phase AC 200 V *2 2.0 KVA *3
Pneumatic Source:
0.5 MPa, 30 L/min (A.N.R.)
Dimensions (mm):
W 1 680 × D 2 070 *4 × H 1 430 *5
Mass:
1730 Kg
Condition:
Used Original
Highlight:

Pick Place Machine SP70

,

Pick Place Machine NM-EJP3A

,

High Speed SMT Screen Printer

Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
USD+negotiable+pcs
Packaging Details
1700*2100*1500mm
Delivery Time
1-7 days
Payment Terms
T/T
Supply Ability
1+pcs+per days
RELATED PRODUCTS
Good price Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder online

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price
Good price Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning online

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price
Good price SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 1000*1100*1300mm Size for 50*50-550*350mm PCB Boards online

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 1000*1100*1300mm Size for 50*50-550*350mm PCB Boards

Get Best Price
Good price Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System online

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price
CONTACT US
Contact Now
Product Description
High Speed SMT Screen Printer Pick Place Machine SP70 NM-EJP3A
Achieve higher quality and productivity with advanced printing technology built on the principle that "the cornerstone of quality is printing."
Key Features & Benefits
  • Excellent Filling Capability & High Productivity: Motor-controlled vertical squeegee motions enable digital control during squeegee uprising, ensuring consistent printing and preventing solder overflow and air mixing issues.
  • PC Board Edge Support: Provides stable support reaching board edges, enabling consistent solder shapes across entire board surfaces for superior printing results.
Technical Specifications
The SP70 NM-EJP3A represents advanced SMT manufacturing technology with precision printing capabilities designed for modern electronics production environments.
SMT Pick And Place Machines SP70 High Speed Screen Printer NM-EJP3A Panasonic SP70 machine Panasonic SP70 specs Panasonic SP70 features Panasonic SP70 maintenance PCB soldering Automatic SMT placement SMT machine calibration
