Name: Panasonic SMT Screen Printer NM-EJP7A with High-Speed Printing and Precision Repeatability ± 5.0 μm ± 3 σ for L 750mm x W 750mm Screen Frames
Brand: Global Soul Limited
SKU: SPV / NM-EJP7A
Availability: InStock

Home > Products > SMT Placement Machine >

Panasonic SMT Screen Printer NM-EJP7A with High-Speed Printing and Precision Repeatability ± 5.0 μm ± 3 σ for L 750mm x W 750mm Screen Frames

5.0 μm SMT Screen Printer

Panasonic Screen Printer

750mm SMT Screen Printer

Place of Origin:

Japan

Brand Name:

Panasonic

Model Number:

SPV / NM-EJP7A

Document:

Product Brochure PDF

Request A Quote

Product Details

Model ID:

SPV

Model No:

NM-EJP7A

PCB Dimensions (mm):

L 50 X W 50 To L 350 X W 300 (Max. Dimensions Of 1 To 2 Spec : L 350 X W 165)

PCB Exchange Time:

10.0 S Including Transfer, Positioning, Recognition, Each-time Cleaning.Printing & Cleaning Conditions : Our Recommended Conditions (PCB Dimensions L 250 X W 165 ) * Except 1 To 2 Spec

Repeatability:

2 Cpk ± 5.0 μm 6 σ The Repeatability Of Same PCB;Equal To ± 5.0 μm ± 3 σ (or ±2.5 μm ±1.5 σ)

Screen Frame Dimensions (mm):

L 736 X W 736, L 650 X W 550, L 550 X W 650, L 750 X W 750, L 584 X W 584*2

Electric Source*3:

1-phase AC 200, 220, 230, 240 V ±10V;Max. 2.0 KVA

Pneumatic Source:

0.5 MPa

Mask Cleaning Suction Blower Spec*4:

280 L/min (A.N.R.)

Mask Cleaning Suction Ejector Spec*4:

380 L/min (A.N.R.)

Dimensions (mm):

W 1 650 X D 1 517 X H 1 500

Mass:

1550 Kg

Highlight:

5.0 μm SMT Screen Printer

Panasonic Screen Printer

750mm SMT Screen Printer

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1700*1600*1600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

Panasonic SMT Screen Printer NM-EJP7A

Technical Specifications

Repeatability	± 5.0 μm ± 3 σ
Screen Frame Dimensions	L 750mm x W 750mm

Key Features

High-Speed Printing

Engineered for speed without compromising accuracy. Advanced printing head and stencil alignment system ensure rapid operation, ideal for high-throughput production lines.

Precision Alignment

Cutting-edge vision system delivers highly accurate stencil alignment, ensuring precise solder paste placement. Reduces defects such as bridging or insufficient solder.

Advanced Cleaning System

Built-in stencil cleaning system prevents paste residue buildup, maintaining consistent print quality throughout production and preventing errors.

Intuitive Software

User-friendly software simplifies setup, operation, and monitoring. Provides real-time data and analytics to optimize manufacturing processes.

Versatility

Handles various PCB sizes, solder paste types, and stencil designs. Adaptable for dynamic manufacturing environments with changing requirements.

Panasonic SPV screen printer Panasonic SPV specifications Panasonic SPV SMT machine Panasonic SPV features Panasonic SPV stencil printer Panasonic SPV accuracy Panasonic SPV maintenance Panasonic SPV spare parts Panasonic SPV printing speed Panasonic SPV alignment system
