Name: Panasonic RL132 SMT Placement Machine with 40 Component Inputs, Maximum Speed 0.14 S/Component, and 360° Insertion Direction
Brand: Global Soul Limited
SKU: RL132 / NM-EJR5A
Availability: InStock

Home > Products > SMT Placement Machine >

Panasonic RL132 SMT Placement Machine with 40 Component Inputs, Maximum Speed 0.14 S/Component, and 360° Insertion Direction

NM-EJR5A SMT Placement Machine

40 Component Inputs SMT Placement Machine

0.14 S/Component SMT Placement Machine

Place of Origin:

Japan

Brand Name:

Panasonic

Model Number:

RL132 / NM-EJR5A

Document:

Product Brochure PDF

Request A Quote

Product Details

Model ID:

RL132

Model No:

NM-EJR5A

PCB Dimensions (mm):

L 50 Mm X W 50 Mm To L 508 Mm X W 381 Mm

Maximum Speed:

0.14 S/component

No. Of Component Inputs:

Applicable Components:

Pitch 2.5/ 5.0 Mm (standard), 7.5 Mm And 10 Mm (option), Resistor, Electrolytic Capacitor, Ceramic Capacitor

PCB Exchange Time:

~2s To About 4s (Room Temperature 20℃)

Insertion Direction:

360° Direction By 1° Increment

Electric Source:

3-phase AC 200 V, 3.5 KVA

Pneumatic Source:

0.5 MPa, 80 L /min (A.N.R.)

Dimensions (mm):

W 2,104 X D 2,183 X H 1,575

Mass:

1,750 Kg

Highlight:

NM-EJR5A SMT Placement Machine

40 Component Inputs SMT Placement Machine

0.14 S/Component SMT Placement Machine

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

2200*2200*1600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

NM-EJR5A SMT Placement Machine With 40 Component Inputs And Maximum Speed 0.14 S/Component

Product Overview

The Panasonic RL132 SMT Placement Machine delivers exceptional performance for high-volume electronics manufacturing with precision placement capabilities and advanced automation features.

Key Features

High-Speed Placement: Achieves maximum placement speeds up to 50,000 components per hour, ensuring efficient mass production throughput.
Advanced Vision System: Incorporates precision alignment technology for accurate component placement, even with miniature and delicate components.
Component Flexibility: Handles diverse component types including fine-pitch components, large packages, and odd-shaped parts with adaptable feeder systems.
Intuitive Operation: Features user-friendly touchscreen interface for simplified control, quick adjustments, and real-time production monitoring.
Robust Construction: Engineered with durable materials for reliable continuous operation in demanding manufacturing environments.

Technical Specifications

Model: NM-EJR5A (Panasonic RL132)
Component Inputs: 40
Maximum Speed: 0.14 seconds per component
Placement Capacity: Up to 50,000 components per hour
Machine Type: SMT Pick and Place with Radial Through-Hole Insertion Capability
