Name: MagicRay 3D SPI-VSP3000 Series SMT Screen Printer For 3D Solder Paste Inspection
Brand: Global Soul Limited
SKU: VSP3000
Availability: InStock

Home > products > SMT Placement Machine >

MagicRay 3D SPI-VSP3000 Series SMT Screen Printer For 3D Solder Paste Inspection

SPI-VSP3000 SMT Screen Printer

Paste Inspection SMT Screen Printer

3D SMT Screen Printer

Brand Name:

MagicRay

Model Number:

VSP3000

Request A Quote

Product Details

Equipment Model:

VSP3000

Image System Camera:

12MP Industrialcamera

Resolution:

15μm,12μm,10μm

FOV:

60*45mm(12MP,15μm)

Height Resolution:

0.37μm

Lighting:

3color Ring ShapeLED(RGB)

Height Measurement Method:

Projectors

Movement Structure:

X/Y Movement

Platform:

Granite

Width Adjustment:

Automatic

Transport Type:

Belt

Board Loading Direction:

Lefttoright Or Right To Left(Select At Point Of Order)

Fixed Rail:

Front Rail

Highlight:

SPI-VSP3000 SMT Screen Printer

Paste Inspection SMT Screen Printer

3D SMT Screen Printer

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1000*1500*1700mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

NM-EJM6D SMT Placement Machine Panasonic NPM-D3 Dual Lane Mode

Get Best Price

High Speed SMT Screen Printer Pick Place Machine SP70 NM-EJP3A

Get Best Price

MagicRay 3D SPI-VSP3000 Series SMT Screen Printer For 3D Solder Paste Inspection

Get Best Price

High Speed SMT Placement Machine Module Z:LEX YSM20 With Dual Lane

Get Best Price

86-0755-27678283

Contact Now

Product Description

MagicRay 3D SPI-VSP3000 series are suitable for 3D solder paste inspection after SMT screen printing.

Product Features
1.Intelligent zero reference point technology ensure accurate height measurement. 2.Effective at detecting solder bridging,solder breakage,icicle,etc.
3.Effective in detecting PCB with different color variations.
4.Automatic compensation for solder pad improves the accuracy of both solder paste heightand volume measurement.
5.SPC data analysis helps to improve process quality.
6.Three Point Checks software helps toquickly detectthe root cause of excess, lack of solder paste andsmearing.

MagicRay 3D SPI-VSP3000 Series SMT Screen Printer For 3D Solder Paste Inspection 0
