Name: High-Efficiency Modular YAMAHA YSM20R SMT Placement Machine with 90,000 CPH and ±0.035mm Accuracy
Brand: Global Soul Limited
SKU: YSM20R
Availability: InStock

Home > Products > SMT Placement Machine >

High-Efficiency Modular YAMAHA YSM20R SMT Placement Machine with 90,000 CPH and ±0.035mm Accuracy

High Efficiency Modular Z:LEX YAMAHA YSM20R

Modular Z:LEX YAMAHA YSM20R

Place of Origin:

Japan

Brand Name:

YAMAHA

Model Number:

YSM20R

Document:

Product Brochure PDF

Request A Quote

High-Efficiency Modular YAMAHA YSM20R SMT Placement Machine with 90,000 CPH and ±0.035mm Accuracy

Product Details

Machine Name:

YSM20R

Applicable PCB:

Dual Stage (only For X Axis 2-beam Specs.)

1 PCB Conveyance:

L810 X W490 To L50 X W50

2 PCB Conveyance:

L380 X W490 To L50 X W50

Single Lane:

L810 X W490 To L50 X W50

Dual Lane (only For X Axis 2-beam Specs.):

L810 X W230 To L50 X W50

Mounting Capability X Axis 2-beam:

High-speed Multi-purpose

Mounting Capability:

90,000 CPH (under Optimum Conditions As Defined By Yamaha Motor)

Mounting Accuracy (Under Optimum Conditions As Defined By Yamaha Motor When Standard Evaluation Mate:

+/-0.035mm (+/-0.025mm) Cpk≧1.0 (3σ)

Applicable Components High-speed Multi-purpose (HM: High-speed Multi) Head X 2:

03015 To 45 X 45mm L100mm, Height 15mm Or Less

Applicable Components Note:

Multi-camera (option) May Be Needed In Some Cases Due To Part Height And Part Size

Applicable Components Odd-shaped Components (FM: Flexible Multi) Head:

03015 To 55 X 55mm L100mm, Height 28mm Or Less

Number Of Component Types Fixed Plate:

Max.140 Types (conversion For 8mm Tape Feeder)

Number Of Component Types Feeder Carriage Exchange:

Max.128 Types (conversion For 8mm Tape Feeder)

Number Of Component Types:

Trays For 30 Types (fixed) And 10 Types (carriage)

Power Supply:

3-Phase AC 200/208/220/240/380/400/416V +/-10% 50/60Hz

Air Supply Source:

0.45MPa Or More, In Clean, Dry State

External Dimension (excluding Projections):

L 1,374 X W 1,857 X H1,445mm

Highlight:

High Efficiency Modular Z:LEX YAMAHA YSM20R

Modular Z:LEX YAMAHA YSM20R

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1500*2000*1600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

High-Efficiency Modular Z:LEX YAMAHA YSM20R

The YAMAHA YSM20R is a high-end, high-efficiency modular mounter designed for modern SMT assembly. Engineered for high-mix, high-volume production environments, this machine offers exceptional speed, precision, and flexibility to meet the demanding requirements of today's surface mount technology industry.

Key Features & Specifications

High-Speed Placement: Up to 95,000 components per hour (CPH) under optimum conditions
Enhanced Accuracy: Placement accuracy of ±0.035mm (±0.025mm) Cpk≧1.0 (3σ)
Wide Component Range: Handles components from 0201mm to 55 x 100mm
Flexible Configurations: Modular design allows easy customization and expansion
Improved Component Adaptability: New wide-scan camera for accurate component recognition
Automatic Pin Support: Program-controlled automatic pin support
No Head Replacement Required: Single head handles 0201mm to large-size components
Optional Features: Enhanced line operating rate without machine stoppage

Applications

The YAMAHA YSM20R is ideal for diverse industries requiring precision SMT assembly:

Mobile Devices Wearable Technology Automotive Electronics Industrial Automation Medical Devices LED Lighting

Technical Specifications

Specification	Value
Maximum Placement Speed	95,000 CPH
Placement Accuracy	±0.035mm (±0.025mm) Cpk≧1.0 (3σ)
Component Size Range	0201mm to 55 x 100mm
Component Support	0201mm to large-size components without head replacement

Frequently Asked Questions

What is the placement speed of the YAMAHA YSM20R?

Maximum placement speed of 95,000 components per hour (CPH) under optimum conditions.

What is the placement accuracy?

Placement accuracy of ±0.035mm (±0.025mm) Cpk≧1.0 (3σ) under optimum conditions.

What is the smallest component size supported?

Components as small as 0201mm can be handled.

What are the key benefits?

High-speed placement, enhanced accuracy, wide component range, flexible configurations, and improved component adaptability.

The YAMAHA YSM20R modular mounter provides an efficient solution for high-volume SMT production, offering seamless integration into existing production lines with minimal disruption. Its versatile design makes it suitable for various printed circuit board assembly applications across multiple industries.
