Name: Full Pneumatic Steel Mesh Cleaning Machine with 360° Rotary Double-Side Isobaric Jet and Two-Stage Filtration System
Brand: Global Soul Limited
SKU: RL-750
Availability: InStock

Home > Products > SMT Placement Machine >

Full Pneumatic Steel Mesh Cleaning Machine with 360° Rotary Double-Side Isobaric Jet and Two-Stage Filtration System

Pneumatic Steel Mesh Cleaning Machine

Steel Mesh Cleaning Machine 600L/Min

Place of Origin:

China

Brand Name:

Model Number:

RL-750

Document:

Product Brochure PDF

Request A Quote

Full Pneumatic Steel Mesh Cleaning Machine with 360° Rotary Double-Side Isobaric Jet and Two-Stage Filtration System

Product Details

Applicable Steel Mesh Size:

L750 × W750 × H40(mm) [large Size Needs To Be Customized]

Dimensions:

L1000*W700*H1730 (mm)

Liquid Tank Maximum Capacity:

40 Liters

Optimal Liquid Usage:

30 Liters

Cleaning Method:

360° Rotary Double-side Isobaric Jet High Pressure Jet (cleaning + Blow Drying)

Cleaning Time:

2-5min

Drying Time:

2-5min

External Air Source:

0.4 ~ 0.6 (Mpa)

Air Consumption:

400 ~ 600(L/Min)

Exhaust Port Size:

Φ125×H25(mm)

Filter System (primary) + Primary Filter Element Filtration:

Filter Impurities And Labels

Filtration System (secondary) + Secondary Filter Element Filtration:

Filter Solder Paste And Rosin Particles

Filtration System (three-stage) + Three-stage Filter Element Filtration:

1 Per Cent (filter Solder Paste And Rosin Particles)

Net Weight:

About 210Kg

Highlight:

Pneumatic Steel Mesh Cleaning Machine

Steel Mesh Cleaning Machine 600L/Min

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1200*800*2000mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

Full Pneumatic Steel Mesh Cleaning Machine

Air Consumption: 400-600L/Min

Product Features

All Stainless Steel Body: Beautiful appearance, excellent wear and corrosion resistance, compliant with environmental standards
Full Pneumatic Operation: No electricity required, eliminating fire and safety hazards
Side Wall Air Intake Blow-Drying: Efficient drying design for optimal results
Humanized Design: One-button operation with automatic filling and draining functions for simple operation
Modular Maintenance: Replaceable controller and quick-plug design for easy maintenance
Advanced Filtration System: Two-stage filtration with low exhaust and S-shaped exhaust pipe design for solvent recycling and low liquid consumption
High-Performance Cleaning: High density isobaric double-sided rotary cleaning nozzles provide strong cleaning force without damaging steel mesh tension
Quality Assurance: Systematic integration of global quality control devices ensures excellent quality, stable performance, and long service life
