Name: Panasonic RG131 SMT Pick And Place Machine with 3 Phase AC 200V High-Speed Operation and Versatile Compatibility
Brand: Global Soul Limited
SKU: NM-EJR3A/NM-EJR4A
Availability: InStock

Home > Products > SMT Placement Machine >

Panasonic RG131 SMT Pick And Place Machine with 3 Phase AC 200V High-Speed Operation and Versatile Compatibility

3 Phase SMT Pick And Place Machines

SMT Pick And Place Machines RG131

Place of Origin:

JAPAN

Brand Name:

Panasonic

Model Number:

NM-EJR3A/NM-EJR4A

Document:

Product Brochure PDF

Request A Quote

Product Details

Model ID:

RG131

Model No:

NM-EJR3A

PCB Dimensions (mm):

L 50 X W 50 To L 508 X W 381

Maximum Speed:

0.25 S/component To 0.6 S/component

No. Of Component Inputs:

80 (Connection Mode), 40 + 40 (Exchange Mode)

Applicable Components:

Pitch 2.5 Mm, 5.0 Mm, 7.5 Mm, 10.0 Mm Height Hn=Max. 26 Mm Diameter D=Max. 18 Mm Resistor, Electrolytic Capacitor, Ceramic Capacitor, LED, Transistor, Filter, Resistor Network

PCB Exchange Time:

~2s To About 4s (Room Temperature 20℃)

Insertion Direction:

4 Directions (0°, 90°, -90°,180°)

Electric Source:

3-phase AC 200 V, 3.5 KVA

Pneumatic Source:

0.5 MPa, 80 L/min (A.N.R.)

Dimensions (mm):

W 3,200 X D 2,417 X H 1,620

Mass:

2,350 Kg

Model No.:

NM-EJR4A

Highlight:

3 Phase SMT Pick And Place Machines

SMT Pick And Place Machines RG131

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

3500*2700*1820mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

3 Phase AC 200V SMT Pick And Place Machines Panasonic RG131 NM-EJR3A NM-EJR4A

The Panasonic RG131 series has made a significant impact in Surface Mount Technology (SMT) manufacturing through its NM-EJR3A and NM-EJR4A models. These precision machines are celebrated for their efficiency, versatility, and reliability, making them essential tools for modern electronics production facilities.

Key Features and Capabilities

High-Speed Operation: Both NM-EJR3A and NM-EJR4A models are engineered for high-speed production, delivering greater throughput without compromising placement quality. Advanced algorithms and motor systems enable rapid component placement, significantly reducing cycle times.
Versatile Component Compatibility: The RG131 series handles a comprehensive range of components, from small passive elements to larger integrated circuits. This versatility makes them ideal for diverse production requirements and mixed-technology assemblies.
Precision Placement Accuracy: Advanced vision systems and feedback mechanisms ensure exceptional placement precision, minimizing errors and rework while maintaining consistent quality across production runs.
User-Friendly Interface: Intuitive control interfaces simplify operation and programming, allowing operators to quickly set up production runs and make adjustments as needed, reducing downtime and training requirements.
Durability and Reliability: Built for high-volume production environments, the RG131 machines feature robust construction and quality components that ensure long-term reliability and lower maintenance costs.
Enhanced Maintenance Features: Designed with easy access to critical components, the NM-EJR3A and NM-EJR4A enable operators to perform routine checks and repairs quickly, minimizing production line disruptions.

Industrial Applications and Benefits

The Panasonic RG131 series, particularly the NM-EJR3A and NM-EJR4A machines, provides comprehensive solutions for electronics manufacturing. Their high-speed operation, versatility, precision placement, and user-friendly design make them indispensable tools for meeting the demanding requirements of modern production lines. Whether upgrading existing equipment or establishing new production capabilities, the RG131 series delivers reliable performance for your SMT manufacturing needs.
