Name: FUJI NXT M3II High-Speed SMT Placement Machine with Modular Configuration and Multi-Nozzle Heads for PCB Assembly
Brand: Global Soul Limited
SKU: NXT M3II
Availability: InStock

Home > Products > SMT Placement Machine >

FUJI NXT M3II High-Speed SMT Placement Machine with Modular Configuration and Multi-Nozzle Heads for PCB Assembly

High Speed SMT PCB Manufacturing

FUJI SMT PCB Manufacturing

SMT Pick And Place PCB Assembly Equipment

Place of Origin:

Japan

Brand Name:

FUJI

Model Number:

NXT M3II

Document:

Product Brochure PDF

Request A Quote

FUJI NXT M3II High-Speed SMT Placement Machine with Modular Configuration and Multi-Nozzle Heads for PCB Assembly

Product Details

Model:

M3II

Series:

Fuji NXT Series

Category:

SMT (Surface Mount Technology) Pick-and-place Machine

Accuracy:

±0.03 Mm (placement Precision, Using Vision Recognition)

Type:

Intelligent, Automatic, And Manual Exchangeable Feeder System

Number Of Feeders:

Supports Up To 130 Feeders Per Module Depending On Configuration

Feeder Types:

Tape Feeders, Tray Feeders, Bulk Feeders, And Stick Feeders

Maximum PCB Size:

508 Mm X 610 Mm (with Dual-lane Configuration)

Minimum PCB Size:

50 Mm X 50 Mm

PCB Thickness:

Supports A Wide Range Of PCB Thicknesses From 0.3 Mm To 4.0 Mm

Multi-Nozzle Placement Heads:

Available In Different Configurations To Meet Various Production Requirements

Types Of Heads:

Standard, High-speed, Or Multi-function Heads That Can Place Components At Different Speeds And Sizes

Power Supply:

3-phase, 200-230V AC, 50/60Hz

Energy Efficiency:

Designed For Optimized Power Usage To Reduce Operational Costs

Machine Dimensions:

Approximately 1,200 Mm (L) X 1,200 Mm (W) X 1,600 Mm (H)

Weight:

Approx. 1,200 Kg (depending On Configuration)

Highlight:

High Speed SMT PCB Manufacturing

FUJI SMT PCB Manufacturing

SMT Pick And Place PCB Assembly Equipment

Payment & Shipping Terms

Minimum Order Quantity

1 pcs

Price

USD+negotiable+pcs

Packaging Details

1700*1700*2100mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

FUJI NXT M3II High Speed SMT PCB Manufacturing Pick And Place PCB Assembly Equipment

The FUJI NXT M3II is a high-performance, modular SMT (Surface Mount Technology) pick-and-place machine designed for precision electronics manufacturing. This advanced system mounts components on printed circuit boards (PCBs) with exceptional speed and accuracy, making it ideal for large-scale production environments.

Machine Functions

High-Speed Placement: Capable of placing a wide range of components at high speed with precision, from microchips to larger components
Modular Configuration: Part of Fuji's NXT series with customizable modules based on production needs, allowing scalability and flexibility
Multi-Nozzle Heads: Equipped with multiple nozzles on placement heads for simultaneous handling of different components
Component Versatility: Places both standard surface-mount devices (SMDs) and odd-shaped components
Automatic Feeder Exchange: Supports automatic and manual feeder exchange to reduce downtime
Camera Inspection: Uses vision system with cameras for accurate component alignment and placement verification
Inline Operation: Designed for seamless integration with other SMT machines in automated production lines
Placement Accuracy: Advanced control and vision systems ensure precise component placement on PCBs

Key Features

Compact Design: Space-efficient footprint optimized for production line integration
Smart Factory Compatibility: Supports Industry 4.0 technologies for data collection and process optimization
User-Friendly Interface: Intuitive controls for quick setup and production monitoring
Intelligent Feeders: Quick recognition of component types minimizes selection errors
Multi-Function Heads: Interchangeable heads capable of component recognition, placement, and inspection functions
Quick Changeover: Fast adaptation between different product types and PCB assemblies
Energy Efficiency: Advanced control systems optimize power consumption and reduce operating costs

Additional Capabilities

Dual Lane Configuration: Parallel production of different PCBs enhances throughput
PCB Handling: Flexible handling options for both large and small boards, adapting to various design requirements

Industry Applications

The FUJI NXT M3II is favored for its adaptability, high speed, and precision, making it ideal for large-scale PCB manufacturing in industries including automotive, consumer electronics, and telecommunications.
