Name: GSCJ-8301B1-5 Automatic PCB Magazine Loader with Handle Adjustment and Plate Metal Base for 355 x 500 x 563 mm Storage
Brand: Global Soul Limited
SKU: GSCJ-8301B1-5
Availability: InStock

Home > Products > ESD Products >

GSCJ-8301B1-5 Automatic PCB Magazine Loader with Handle Adjustment and Plate Metal Base for 355 x 500 x 563 mm Storage

Automatic PCB Magazine Loader

Automatic PCB Magazine Unloader

GSCJ-8301B1-5 Automatic PCB Loader

Place of Origin:

China

Brand Name:

Model Number:

GSCJ-8301B1-5

Document:

Product Brochure PDF

Request A Quote

Product Details

Size:

355 X 500 X 563 Mm

Adjustment Method:

Handle

Base Material:

Plate Metal

Reference Position:

A34 Mm, B34 Mm

Side Board Structure:

5 Sheets

Lead Time:

1-7 Days

Highlight:

Automatic PCB Magazine Loader

Automatic PCB Magazine Unloader

GSCJ-8301B1-5 Automatic PCB Loader

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

380*520*580mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

GSCJ-8301B1-5 Automatic PCB Magazine Loader with Handle Adjustment and Plate Metal Base for 355 x 500 x 563 mm Storage

Get Best Price

Aluminum Alloy Anti Static PCB Magazine Rack with Adjustable Width 85-250 mm for SMT Loader and Unloader

Get Best Price

GSCJ-8301B1 SMT PCB Magazine Rack with 50 PCB Slots and Adjustable Width 35-250 mm for ESD PCB Storage

Get Best Price

GSCJ-8301B1-1 Anti-Static SMT Loading and Unloading Rack with 50 PCB Slots for PCB Transfer Box (355 x 320 x 563 mm)

Get Best Price

Contact Now

Product Description

GSCJ-8301B1-5 PCB Magazine Loader And Unloader Rack Automatic PCB Loader

GSCJ-8301B1-5 Loading and Unloading Rack for PCBs - Automatic PCB Loader with Storage and Transfer Frame for Circuit Boards and Substrate Boxes

GSSMT, PCB Magazine Loader, PCB Magazine Rack, SMT PCB Magazine, PCB Magazine Unloader, PCB Magazine Handling, PCB Magazine Storage, PCB Magazine Transport, PCB Magazine Capacity, PCB Magazine Holder, PCB Magazine System

Installation Guide

1. Install the Rack: Ensure the rack is aligned and flush with the base plate.

2. Secure the Columns: Use screws to fix the four columns firmly.

3. Attach the Side Panel: Align the holes and tighten the screws.

4. Position the Movable Side Panel: Ensure the bottom edge is close to the rack.

5. Install the Base Plate: Push the circular pin of the latch upward and move the side panel.

6. Install the Stopper: Attach it at the spring position, facing downward.

Special Installation Note

Pay attention to steps 4 and 5. The circular pin of the latch must align precisely with the circular hole on the base plate. Accurate positioning is crucial to avoid misalignment; ensure synchronization in all directions.
