Name: GSCJ-8301A-1 PCB Magazine Rack SMT Loading and Unloading Rack with 355 x 315 x 320 mm Size 25 Slots and Adjustable Width 85-250 mm
Brand: Global Soul Limited
SKU: GSCJ-8301A-1
Availability: InStock

Home > Products > ESD Products >

GSCJ-8301A-1 PCB Magazine Rack SMT Loading and Unloading Rack with 355 x 315 x 320 mm Size 25 Slots and Adjustable Width 85-250 mm

PCB Magazine Automatic

PCB Magazine SMT

Place of Origin:

China

Brand Name:

Model Number:

GSCJ-8301A-1

Document:

Product Brochure PDF

Request A Quote

Product Details

Size:

355 X 315 X 320 Mm

Adjustment Method:

Screw Adjustment

Slot Depth:

3.5 Mm

Slot Width:

7 Mm

Pitch:

10 Mm

Number Of Slots:

Reference Position A:

34mm

Reference Position B:

35.5 Mm

Adjustable Width:

85-250 Mm

Side Board Structure:

Solid Panel

Highlight:

PCB Magazine Automatic

PCB Magazine SMT

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+PCS

Packaging Details

400*350*350mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

10000+PCS+per days

GSCJ-8301B1-5 Automatic PCB Magazine Loader with Handle Adjustment and Plate Metal Base for 355 x 500 x 563 mm Storage

Get Best Price

Aluminum Alloy Anti Static PCB Magazine Rack with Adjustable Width 85-250 mm for SMT Loader and Unloader

Get Best Price

GSCJ-8301B1 SMT PCB Magazine Rack with 50 PCB Slots and Adjustable Width 35-250 mm for ESD PCB Storage

Get Best Price

GSCJ-8301B1-1 Anti-Static SMT Loading and Unloading Rack with 50 PCB Slots for PCB Transfer Box (355 x 320 x 563 mm)

Get Best Price

Contact Now

Product Description

GSCJ-8301A-1 PCB Magazine SMT Automatic PCB Circuit Board Loading And Unloading Rack

The GSCJ-8301A-1 PCB Magazine SMT Automatic Loading and Unloading Rack is a specialized PCB circuit board loader designed for efficient SMT manufacturing processes. This system provides reliable handling, storage, and transport of PCB magazines within automated production lines.

PCB Magazine Loader PCB Magazine Rack SMT PCB Magazine PCB Magazine Unloader PCB Magazine Handling PCB Magazine Storage PCB Magazine Transport PCB Magazine Capacity PCB Magazine Holder PCB Magazine System

Installation Guide

Install the Rack: Ensure the rack is aligned and flush with the base plate.
Secure the Columns: Use screws to fix the four columns firmly.
Attach the Side Panel: Align the holes and tighten the screws.
Position the Movable Side Panel: Ensure the bottom edge is close to the rack.
Install the Base Plate: Push the circular pin of the latch upward and move the side panel.
Install the Stopper: Attach it at the spring position, facing downward.

Special Installation Note: Pay particular attention to steps 4 and 5. The circular pin of the latch must align precisely with the circular hole on the base plate. Accurate positioning is crucial to avoid misalignment; ensure synchronization in all directions for proper operation.
