Anti Static PCB Magazine Rack with Adjustable Width 35-250 mm and 25 PCB Slots for SMT Transfer Cart

Product Details

Size:

355 X 320 X 563 Mm

Adjustment Type:

Handle

Slot Depth:

3.5 Mm

Slot Width:

7 Mm

Pitch:

20 Mm

PCB Slots:

Reference Position:

A34 Mm, B34 Mm

Adjustable Width:

35-250 Mm

Base Material:

Metal

Side Board Structure:

5 Sheets

Weight:

5.6kg

Condition:

Original New

Highlight:

PCB Magazine Material Rack

PCB Magazine Transfer Cart

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

380*360*600mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

GSCJ-8301B1-5 Automatic PCB Magazine Loader with Handle Adjustment and Plate Metal Base for 355 x 500 x 563 mm Storage

Get Best Price

Aluminum Alloy Anti Static PCB Magazine Rack with Adjustable Width 85-250 mm for SMT Loader and Unloader

Get Best Price

GSCJ-8301B1 SMT PCB Magazine Rack with 50 PCB Slots and Adjustable Width 35-250 mm for ESD PCB Storage

Get Best Price

GSCJ-8301B1-1 Anti-Static SMT Loading and Unloading Rack with 50 PCB Slots for PCB Transfer Box (355 x 320 x 563 mm)

Get Best Price

Contact Now

Product Description

Anti Static PCB Magazine Material Rack Transfer Cart SMT Peripheral Equipment

Installation Guide

Install the Rack: Ensure the rack is flush with the base plate.

Secure the Four Upright Posts: Use screws to fix all four upright posts firmly.

Attach the Fixed Side Panel: Align the holes and tighten the screws to secure the fixed side panel.

Position the Movable Side Panel: The bottom of the movable side panel should align closely with the edge of the rack.

Install the Base Plate: Push the circular locking pins on the clips upwards, then move the movable side panel into place.

Attach the Stopper: Insert the stopper at the spring position, ensuring it faces downward to complete the installation.

Special Installation Note

Pay extra attention to Step 4 and Step 5. Ensure the circular locking pins on the clips align precisely with the circular holes on the base plate. Proper alignment is crucial, and synchronization in both vertical and horizontal directions is necessary. Failure to do so may result in gear skipping.
