GSCJ-8301B1-1 SMT Anti Static Loading And Unloading Rack For Motherboard Frame PCB Transfer Box

Installation Guide
Install the Rack: Ensure the rack is aligned and flush with the base plate.
Secure the Columns: Use screws to fix the four columns firmly.
Attach the Side Panel: Align the holes and tighten the screws.
Position the Movable Side Panel: Ensure the bottom edge is close to the rack.
Install the Base Plate: Push the circular pin of the latch upward and move the side panel.
Install the Stopper: Attach it at the spring position, facing downward.
Special Note: Pay attention to steps 4 and 5. The circular pin of the latch must align precisely with the circular hole on the base plate. Accurate positioning is crucial to avoid misalignment; ensure synchronization in all directions.
