Name: Aluminum Alloy Anti Static PCB Magazine Rack with Adjustable Width 85-250 mm for SMT Loader and Unloader
Brand: Global Soul Limited
SKU: GSCJ-8301A
Availability: InStock

Home > Products > ESD Products >

Aluminum Alloy Anti Static PCB Magazine Rack with Adjustable Width 85-250 mm for SMT Loader and Unloader

Anti Static PCB Magazine

Aluminum Alloy PCB Magazine

Place of Origin:

China

Brand Name:

Model Number:

GSCJ-8301A

Document:

Product Brochure PDF

Request A Quote

Product Details

Size:

355 X 315 X 580 Mm

Adjustment Type:

Screw

Slot Depth:

3.5 Mm

Slot Width:

7 Mm

Pitch:

10 Mm

PCB Slots:

Reference Position:

A34 Mm, B35.5 Mm

Adjustable Width:

85-250 Mm

Side Board Structure:

Whole Panel

Weight:

4.75 Kg

Highlight:

Anti Static PCB Magazine

Aluminum Alloy PCB Magazine

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

400*350*600 mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

GSCJ-8301B1-5 Automatic PCB Magazine Loader with Handle Adjustment and Plate Metal Base for 355 x 500 x 563 mm Storage

Get Best Price

Aluminum Alloy Anti Static PCB Magazine Rack with Adjustable Width 85-250 mm for SMT Loader and Unloader

Get Best Price

GSCJ-8301B1 SMT PCB Magazine Rack with 50 PCB Slots and Adjustable Width 35-250 mm for ESD PCB Storage

Get Best Price

GSCJ-8301B1-1 Anti-Static SMT Loading and Unloading Rack with 50 PCB Slots for PCB Transfer Box (355 x 320 x 563 mm)

Get Best Price

Contact Now

Product Description

Aluminum Alloy Anti Static PCB Magazine Rack For SMT Loader And Unloader PCB Storage

Product Assembly Instructions

Install the Rack: Ensure that the rack fits snugly against the base plate.
Secure the Four Upright Columns: Use screws to firmly attach all four upright columns in place.
Attach the Side Panel: Align the side panel with the designated holes and tighten the screws.
Adjust the Movable Side Panel: Position the bottom edge of the movable side panel flush with the rack edge.
Install the Base Plate: Push the round pin of the latch upward, then slide the side panel to align properly.
Install the Stopper on the Spring Area: Attach the stopper, positioning it downward to complete the installation.

Special Note: Pay careful attention to steps 4 and 5. Ensure the round pin on the latch aligns precisely with the circular hole on the base plate. Proper positioning is crucial—both horizontally and vertically—to prevent gear slipping or misalignment.
