High Speed Dispenser with 720’000 dots/h, 40 μm Accuracy, and Expandable Design for SMT Placement Machine

high speed smt pick and place machines

high speed smt pick and place equipment

Place of Origin:

Switzerland

Brand Name:

Essemtec

Model Number:

FOX

Document:

Product Brochure PDF

Request A Quote

High Speed Dispenser with 720’000 dots/h, 40 μm Accuracy, and Expandable Design for SMT Placement Machine

Product Details

Process Maximum Dispensing Speed Piezo Jet Valve:

> 720’000 Dots/h

Dynamic Shockwave Valve:

720‘000 Dots/h

Time/Pressure Valve:

28‘000 Dots/h

Archimedean Screw Valve:

24‘000 Dots/h

Dispensing Mode:

Dot, Line, Curve, Interpolated 3D Contour

Accuracy Placement XY Dots:

40 μm (3σ)

Accuracy Positioning Z Axis:

20 μm (3σ)

PCB Dimensions:

50 X 50 Mm Bis Zu 406 X 305 Mm (2 X 2” Up To 16 X 12”)

Dimensions Machine Footprint:

880 X 1090 Mm (34.7 X 43”)

Condition:

Original New/Used Origianl

Highlight:

high speed smt pick and place machines

high speed smt pick and place equipment

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1000*1200*2000mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Panasonic BM123 SMT Pick And Place Machine with 0.12s/chip Max Speed 50μm Placement Accuracy and 160 Double Tape Feeder

Get Best Price

Electric Steel Mesh Cleaning Machine with 25KW Power Double Liquid Tank and High Pressure Spray for SMT Cleaning

Get Best Price

SMT Cooling Temporary Storage Machine with 130℃ to 30℃/60s Cooling Range and 100011001300mm Size for 5050-550350mm PCB Boards

Get Best Price

Panasonic NPM-D3A SMT Pick And Place Machine with Dual-Lane Capability High-Speed Performance and Advanced Vision System

Get Best Price

Contact Now

Product Description

SMART-SIZED HIGH SPEED DISPENSER

Introducing Fox Technology - the advanced solution for all types of components and devices. This high-speed dispenser system offers exceptional expandability in any direction, making it ideal for diverse manufacturing applications.

Capable of driving up to 200 feeders for high-mix production environments
Compact footprint and reasonable weight for space-constrained facilities
Suitable for use in limited space production areas, including upper floor locations
Optimized for high-speed dispensing operations with maximum efficiency
