Name: ZK Series SMT Vacuum Bare Board Loader with PLC Control 220V Power Supply and 200pcs Capacity
Brand: Global Soul Limited
SKU: ZK-650 / ZK-800 / ZK-1500-460
Availability: InStock

Home > Products > PCB Handling Equipment >

ZK Series SMT Vacuum Bare Board Loader with PLC Control 220V Power Supply and 200pcs Capacity

Vacuum Bare Board Loader 220V

SMT Bare Board Loader

PLC Bare Board Loader

Place of Origin:

China

Brand Name:

Model Number:

ZK-650 / ZK-800 / ZK-1500-460

Document:

Product Brochure PDF

Request A Quote

Product Details

Description:

Used To Automatically Send Circuit Boards To The Production Line

Time For Feed PCBs:

Approx. 8 Seconds Or Specified By Customer

Board Maximum Capacity:

200pcs(0.6mm Thick PCB)

Power Supply And Electric Load:

220V(AC,SP)120VA Max

Air Pressure And Air Flow:

4~6bar, Up To 30 L/min

Thickness Of PBCs:

0.6mm Min

Highlight:

Vacuum Bare Board Loader 220V

SMT Bare Board Loader

PLC Bare Board Loader

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1600*1350*1350mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers

Get Best Price

Video

Lead Free Nitrogen Hot Air Reflow Oven with Siemens PLC Control and Modular Design for SMT Production

Get Best Price

ZCL300-D Series Dual Buffer Stocker with Double Track Cache Cooling Function and 20-30pcs Capacity for PCB Handling

Get Best Price

PTH Series PCB Conveyor with PLC Control System Stepping Drive and SMEMA Communication for Efficient PCB Handling

Get Best Price

Contact Now

Product Description

ZK Series SMT Vacuum Bare Board Loader PLC Controlled 220V

Advanced automated loading solution for SMT production lines with PLC control and vacuum board handling.

ZK Series Vacuum Bare Board Loader Features

SMT production line circuit board upper board device
PLC control with color HMI operation system
Multiple independent vacuum generating systems for stable and reliable adsorption
Automatically rising and falling platform for faster operation
PLC control system with multiple electrical circuit protection for security and stability
Sound and light alarm system with text prompts for easy operation and maintenance
Standard SMEMA signal communication
