Name: 67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers
Brand: Global Soul Limited
SKU: GSKL-650
Availability: InStock

Home > Products > PCB Handling Equipment >

67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers

Hot Air Curing Oven 67KW

Vertical Hot Air Curing Oven

Place of Origin:

China

Brand Name:

Model Number:

GSKL-650

Document:

Product Brochure PDF

Request A Quote

67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers

Product Details

Model:

GSKL-650

Applicable Production Range:

Curing After Dispensing Or Pasting Of Consumer Electronincs

Dimensions(mm):

2150(L)*2050(W)*2150(H)

Weight(Kg):

<2000KG

Heating Time:

10minute

Temperature Setting Range:

Room Temperature – 200°C

Control Method:

PID Closed-loop Control +SSR Drive

Number Of Temperature Zones:

Heating Mode:

Large Circulation Of Hot Air, Two Sides Blowing And Top Return Air

PCB Boad Temperature Distribution Deviation:

±3.0°C

Min Beat:

15S

PCB Maximum Size(mm):

650(L)×460(W)

Rail Width Adjustment Range:

80~460mm

Track Width Adjustment:

Automatic Width Adjustment, And Fixed Track Near The Operating Surface

Product Flow:

From Left To Right

Layer Spacing:

20mm

Transport Height（mm）:

950±30mm

Number Of Layers:

60 Layers

Installed Power:

67KW

Highlight:

Hot Air Curing Oven 67KW

Vertical Hot Air Curing Oven

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

2300*2100*2250mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers

Get Best Price

Video

Lead Free Nitrogen Hot Air Reflow Oven with Siemens PLC Control and Modular Design for SMT Production

Get Best Price

ZCL300-D Series Dual Buffer Stocker with Double Track Cache Cooling Function and 20-30pcs Capacity for PCB Handling

Get Best Price

PTH Series PCB Conveyor with PLC Control System Stepping Drive and SMEMA Communication for Efficient PCB Handling

Get Best Price

Contact Now

Product Description

Material Frame Vertical Hot Air Curing Oven 67KW

Advanced material frame vertical hot air curing oven designed for efficient and reliable industrial curing processes.

Key Features & Advantages

Scientific Transmission Design: Internal transmission system eliminates connection points, ensuring smooth transportation and minimizing jamming risks.
Intelligent Fault Shielding: Advanced operating system allows selective shielding of faulty layers during equipment operation, maintaining productivity without complete shutdown.
Adjustable Operation Range: Enables small cycle actions where products don't need to pass through the top layer, resulting in significant energy savings and reduced consumption.
Innovative Needle Roller Transportation: Advanced active transportation system prevents jamming and plate damage, unlike traditional chain-driven systems that can cause product damage during jams.

Material Frame Vertical Hot Air Curing Oven | GSSMT, Material frame vertical curing oven, Vertical curing oven for material frames, Frame-based vertical curing oven, Material frame hot air curing oven, Vertical curing oven with material frame, Industrial frame curing oven, Vertical curing oven for SMT frames, Vertical oven for frame material curing, Material frame curing system, High-temperature material frame oven, Vertical curing oven for electronics frames, Material frame vertical heating oven, Precision material frame curing oven, Frame curing vertical oven, Material frame vertical oven system, Automated material frame curing oven, SMT material frame curing oven, Frame-based vertical curing equipment, Vertical curing oven for PCB frames, Material frame curing chamber vertical
