ZL Series Vertical Entry Unloader with PLC Control Stepping Motor Push Plate Structure and SMEMA Signal Communication

ZL Series Vertical Entry Unloader with PLC Control Stepping Motor Push Plate Structure and SMEMA Signal Communication

smt pcb magazine loader

smt pcb handling machine

automatic pcb magazine loader

Place of Origin:

China

Brand Name:

GS

Model Number:

ZL-3BM / ZL-3BL / ZL-3BLL / ZL-3BXL

Document:

Product Brochure PDF

Contact Us
Request A Quote
ZL Series Vertical Entry Unloader with PLC Control Stepping Motor Push Plate Structure and SMEMA Signal Communication
ZL Series Vertical Entry Unloader with PLC Control Stepping Motor Push Plate Structure and SMEMA Signal Communication
Product Details
Description:
For Automatic Collection Of Circuit Boards From The Production Line
No. Of Magazine:
Upper Conveyor: 1nos.Lower Conveyor:2nos.
Time For Feed PCBs:
Approx. 6 Seconds Or Specified By Customer
Magazine Change Over Time:
Approx.35 Seconds Or Specified By Customer
Indexing Pitch:
10,20,30,40 Mm Pitch Or Specified By Customer
Power Supply And Electric Load:
220V(AC,SP)300VA Max
Air Pressure And Air Flow:
4~6bar, Up To 0.1
Thickness Of PBCs:
0.6mm Min
Highlight:

smt pcb magazine loader

,

smt pcb handling machine

,

automatic pcb magazine loader

Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
USD+negotiable+pcs
Packaging Details
1560*1790*1400mm
Delivery Time
1-7 days
Payment Terms
T/T
Supply Ability
1+pcs+per days
RELATED PRODUCTS
Good price 67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers online

67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers

Get Best Price
Good price Lead Free Nitrogen Hot Air Reflow Oven with Siemens PLC Control and Modular Design for SMT Production online Video

Lead Free Nitrogen Hot Air Reflow Oven with Siemens PLC Control and Modular Design for SMT Production

Get Best Price
Good price ZCL300-D Series Dual Buffer Stocker with Double Track Cache Cooling Function and 20-30pcs Capacity for PCB Handling online

ZCL300-D Series Dual Buffer Stocker with Double Track Cache Cooling Function and 20-30pcs Capacity for PCB Handling

Get Best Price
Good price PTH Series PCB Conveyor with PLC Control System Stepping Drive and SMEMA Communication for Efficient PCB Handling online

PTH Series PCB Conveyor with PLC Control System Stepping Drive and SMEMA Communication for Efficient PCB Handling

Get Best Price
CONTACT US
Contact Now
Product Description
SMT Peripheral Equipment ZL Series Vertical Entry Unloader
Product Features
  • Perpendicular output direction to line body, effectively shortening overall line length
  • SMT production line circuit board upper board device
  • PLC control with color HMI operation system
  • Stepping motor push plate structure with adjustable pushing speed
  • Auxiliary positioning braking system for accurate positioning and fast lifting speed
  • Multiple electrical distribution circuit protection for safe and reliable operation
  • Sound and light alarm system with text prompts for easy operation and maintenance
  • Standard SMEMA signal communication
  • Optional AGV docking function available
Related Keywords:
SMT Peripheral Equipment ZL series Vertical Entry Unloader | GSSMT, SMT vertical entry unloader, Vertical PCB unloader, Vertical magazine unloader, Vertical SMT unloader, High-speed vertical unloader, PCB vertical entry unloader, Vertical entry unloader machine, Compact vertical entry unloader, Vertical PCB magazine unloader, Fully automatic vertical unloader, SMT vertical magazine unloader, Vertical entry PCB handling, Vertical unloader for SMT production, PCB vertical unloader system, Vertical SMT assembly unloader, Advanced vertical entry unloader
