SMT Series PCB Conveyor Machine Side Entry Unloader with PLG Control Stepping Motor Push Plate Structure and SMEMA Signal Communication

smt pcb magazine loader

smt pcb handling machine

Place of Origin:

China

Brand Name:

Document:

Product Brochure PDF

Request A Quote

Product Details

Description:

Used To Automatically Send Out Circuit Boards To The Production Line

No. Of Magazine:

Upper Conveyor: 1nos.Lower Conveyor:2nos

Time For Feed PCBs:

Approx. 6 Seconds Or Specified By Customer

Magazine Change Over Time:

Approx.35 Seconds Or Specified By Customer

Indexing Pitch:

10,20,30,40 Mm Pitch Or Specified By Customer

Power Supply And Electric Load:

220V(AC,SP)300VA Max

Air Pressure And Air Flow:

4~6bar, Up To 0.1

Thickness Of PBCs:

0.6mm Min

Highlight:

smt pcb magazine loader

smt pcb handling machine

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

2000*1000*1300mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

67KW Material Frame Vertical Hot Air Curing Oven with PID Closed-Loop Control and 60 Layers

Get Best Price

Video

Lead Free Nitrogen Hot Air Reflow Oven with Siemens PLC Control and Modular Design for SMT Production

Get Best Price

ZCL300-D Series Dual Buffer Stocker with Double Track Cache Cooling Function and 20-30pcs Capacity for PCB Handling

Get Best Price

PTH Series PCB Conveyor with PLC Control System Stepping Drive and SMEMA Communication for Efficient PCB Handling

Get Best Price

Contact Now

Product Description

SMT Series PCB Conveyor Machine Side Entry Unloader

Product Overview

Advanced side entry unloader designed for SMT production lines, providing efficient circuit board handling with precision control and safety features.

Key Features

SMT production line circuit board upper board device
PLC control with color HMI operation system
Stepping motor push plate structure with adjustable pushing speed
Auxiliary positioning braking system for accurate positioning and fast lifting
Multiple electrical distribution circuit protection for safe, reliable operation
Sound and light alarm system with text prompts for easy operation and maintenance
Standard SMEMA signal communication
Optional AGV docking function available
