Name: Single Channel Pallet Cabinet SMT Feeder with 750W Maximum Power and Panasonic Brand Components
Brand: Global Soul Limited
SKU: GS-JAT2501
Availability: InStock

Home > Products > SMT Feeder >

Single Channel Pallet Cabinet SMT Feeder with 750W Maximum Power and Panasonic Brand Components

Single Channel Pallet Cabinet

750W Maximum Power SMT Feeder

Panasonic Brand Components Component Supply Device

Place of Origin:

China

Brand Name:

Model Number:

GS-JAT2501

Document:

Product Brochure PDF

Request A Quote

Product Details

Model:

GS-JAT2501

External Dimensions (length * Width * Height Single. Position: Mm):

1380*700*1361.5

Weight:

213.5KG

Working Voltage:

AC220V

Gas Source Requirements:

0.5-0.7Mpa

Maximum Power:

750W

Feeding Speed:

7-inch [IPS 1024*600] Display Screen

Channel:

Single Channel

Function:

Optional Separately【Default None】

Adapted Material Tray:

Please Refer To The Following Drawings

Whole Machine Configuration:

The Sensor, Sensor And Servo Controller Adopt Panasonic Brand, The Motor Adopts Panasonic And Lesai Brand, The Cylinder Adopts Airtek, The Main Control Board Brand Is Lesai, The Lead Screw Module Is Yiheda, And The Control System Adopts Industrial Control

Condition:

New

Highlight:

Single Channel Pallet Cabinet

750W Maximum Power SMT Feeder

Panasonic Brand Components Component Supply Device

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

1550*850*1500

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Yamaha ZS 104mm SMT Feeder for Pick & Place Machines - Japan Origin & Yamaha Brand

Get Best Price

YAMAHA Brand Electric Drive SMT Feeder Car with Multiple Model Compatibility for Feeder Storage and Placement

Get Best Price

YAMAHA SMT Feeder Rack Stainless Steel 2 Floors Design with Universal Wheel and Brake for YS12/10/20/SS Feeder Car

Get Best Price

SMT Feeder Car with High Quality Aluminum Construction 100 Feeder Capacity and Anti-Static Drag Chain for Efficient SMT Production

Get Best Price

Contact Now

Product Description

Pallet Cabinet GS-JAT2501 (Single Track)

The GS-JAT2501 Pallet Cabinet is an automated component supply device that sequentially dispenses multiple palletized materials at specified intervals and supplies them directly to insertion machines.

Technical Specifications

Parameter	Specification
Voltage	220V
Air Pressure	4-7 BAR
Feeding Speed	Continuous feeding: 2 seconds * 10 pieces Pallet transfer to material track: approx. 3 seconds per piece
Maximum Pallet Size	L240 * W350 * H30mm (15 pallets capacity)

Operational Process

A. Pallet Placement Area: Manual placement of empty and loaded material packaging trays. Base trays can be pulled out for placement, enabling continuous operation without machine stoppage (follow display screen prompts).

B. Material Transfer Area: Equipment extracts and elevates loading base trays. XY axis equipped with suction cups or clamps transfers materials from set tray coordinates to discharge track.

C. Discharge Area: Materials are conveyed using belts or direct vibration (method adjustable per equipment model) to the material retrieval area.

D. Material Retrieval Area: Insertion machine collects materials at this position. Material flipping operations occur at retrieval position if required.

Note: For pallet sizes exceeding standard range, equipment external dimensions require customization.

Custom Solutions Available: For special material dimensions or unique requirements, contact our engineering team for customized feeder solutions tailored to your specific application needs.
