Name: Jumper Feeder (GS-LAD2303)
Brand: Global Soul Limited
SKU: GS-LAD2303
Availability: InStock

Home > products > SMT Feeder >

Jumper Feeder (GS-LAD2303)

Place of Origin:

China

Brand Name:

Model Number:

GS-LAD2303

Document:

Product Brochure PDF

Request A Quote

Product Details

Model:

GS-LAD2303

Overall Dimensions (length * Width * Height):

624*78*160

Weight:

6.5KG

Working Voltage:

DC 24V

Gas Source Requirements:

Maximum Current:

2.5A

Feeding Speed:

1.5s/Pcs

Operation Panel:

0.96-inch TFT Color Screen, 80*160 Pixels

Material Change Time:

3min

Channel:

Single Channel

Pin Bending Function:

Bend

Lifting Function:

Lifting Feeding

Foot Cutting Function:

Cut Off

Straightening Function:

Alignment Of Alignment

Material Wire Diameter:

0.4-0.7mm(The Bending Module Needs To Be Replaced When Changing The Wire Diameter)【It Is Not Adjustable. For Example, For A 0.6mm Module, Only 0.6mm Iron Wire Can Be Drawn】

Jumper Span 1:

5-26mm(Change The Length Of The Fixture When Changing The Span)【It Is Not Adjustable. For Example, For A 16mm Span, Only A 16mm Length Fixture Can Be Used】

Jumper Span 2:

The Maximum Span Is 35mm(the Arc-shaped Deformation Of The Product Will Be Larger).【It Is Not Adjustable. For Example, For A 16mm Span, Only A 16mm Length Fixture Can Be Used】

The Length Of The Formed Pins:

2.0~5.5mm【Within This Range, It Can Be Achieved By Replacing The Fixture. One Fixture Can Only Correspond To A Single Size】

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

850*90*180

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

KLJ-MCA00-100 Yamaha ZS 104mm Feeder

Get Best Price

YAMAHA Mounter YS Feeder Rack Stainless Steel YS12/10/20/SS Feeder Car Placement Car

Get Best Price

YAMAAH SMT Machine YSM10 YS24 Smt Feeder Rack Electric Feeder Car Feeder Storage Car Placement Car

Get Best Price

SMT Machine Samsung Hanwha SM Electric / Pneumatic Feeder SMT Feeder Rack Placing

Get Best Price

86-0755-27678283

Contact Now

Product Description

Jumper Feeder (GS-LAD2303)

The jumper feeder is a component supply device that sends out the coiled copper wires one by one according to a fixed length, cuts them into shape and supplies them to the insertion machine.

Jumper Feeder (GS-LAD2303) 0

Jumper Feeder (GS-LAD2303) 1

Jumper Feeder (GS-LAD2303) 2

Jumper Feeder (GS-LAD2303) 3

Jumper Feeder (GS-LAD2303) 4

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
