Name: 70mm Vertical Feeder with Cutter for SMT Component Supply Device DC 24V
Brand: Global Soul Limited
SKU: GS-RAD2201
Availability: InStock

Home > Products > SMT Feeder >

70mm Vertical Feeder with Cutter for SMT Component Supply Device DC 24V

70mm Vertical Feeder

With Cutter SMT Feeder

DC 24V Component Supply Device

Place of Origin:

China

Brand Name:

Model Number:

GS-RAD2201

Document:

Product Brochure PDF

Request A Quote

70mm Vertical Feeder with Cutter for SMT Component Supply Device DC 24V

Product Details

Model:

GS-RAD2201

External Dimensions (length * Width * Height）:

750*68*144(110)mm[The Height From The Bottom To The Feeding Port: 110cm Height At The Highest Point (from The Bottom To The Handle) : 144mm]

Weight:

8KG

Working Voltage:

DC 24V

Gas Source Requirements:

Maximum Current:

Feeding Speed:

0.6-2s/Pcs

Drive Mode:

Pure Electric

Operation Panel:

0.96-inch TFT Color Screen 80*160 Pixels

Error In The Length Of The Material Cutting Feet:

±0.2mm

Applicable To The Hole Spacing Of The Tape:

12.7mm/15mm(Parts Need To Be Replaced)

Function Of Cutting Waste Tape:

Optional[ GS-RAD2201: With A Cutter GS-RAD2107: No Cutter]

Bending Function:

Optional Separately[The Bending Function Can Be Customized According To The Material]

The Number Of Times The Cutter Is Used:

≥1 Million

Highlight:

70mm Vertical Feeder

With Cutter SMT Feeder

DC 24V Component Supply Device

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

900*95*175mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Yamaha ZS 104mm SMT Feeder for Pick & Place Machines - Japan Origin & Yamaha Brand

Get Best Price

YAMAHA Brand Electric Drive SMT Feeder Car with Multiple Model Compatibility for Feeder Storage and Placement

Get Best Price

YAMAHA SMT Feeder Rack Stainless Steel 2 Floors Design with Universal Wheel and Brake for YS12/10/20/SS Feeder Car

Get Best Price

SMT Feeder Car with High Quality Aluminum Construction 100 Feeder Capacity and Anti-Static Drag Chain for Efficient SMT Production

Get Best Price

Contact Now

Product Description

70mm Vertical Feeder (GS-RAD2201) [With Cutter]

Product Overview

The GS-RAD2201 70mm Vertical Feeder is an advanced electronic component supply device designed for large materials. This precision feeder maintains consistent intervals and delivers vertically packaged electronic components one by one at specified times, while cutting lead wires and supplying components directly to insertion machines.

Key Features

70mm vertical feeder design optimized for large component handling
Integrated cutter for precise lead wire cutting
Maintains consistent component spacing and timing
Automated supply to insertion machines
Specifically designed for vertical tape packaging components

Product Images

Custom Solutions Available

For special material dimensions or unique application requirements, contact our engineering team for consultation. We provide customized solutions and develop exclusive feeders tailored to your specific manufacturing needs.
