Name: Dual-channel Tubular Feeder with 2s/Pcs Feeding Speed and OLED Display Screen for SMT Rail Vibration Feeding
Brand: Global Soul Limited
SKU: GS-SAT2112
Availability: InStock

Home > Products > SMT Feeder >

Dual-channel Tubular Feeder with 2s/Pcs Feeding Speed and OLED Display Screen for SMT Rail Vibration Feeding

Dual-channel Tubular Feeder

2s/Pcs Feeding Speed SMT Feeder

OLED Display Screen Rail Vibration Feeder

Place of Origin:

China

Brand Name:

Model Number:

GS-SAT2112

Document:

Product Brochure PDF

Request A Quote

Dual-channel Tubular Feeder with 2s/Pcs Feeding Speed and OLED Display Screen for SMT Rail Vibration Feeding

Product Details

Model:

GS-SAT2109

Overall Dimensions (length * Width * Height):

1500*90*1140mm

Weight:

40KG

Working Voltage:

AC 220V

Gas Source Requirements:

0.5-0.7Mpa

Maximum Current:

Feeding Speed:

2s/Pcs

Operation Panel:

1.54-inch OLED Display Screen

Pipe Replacement Time:

<6S

Channel:

Dual-channel

Pin Bending Function:

Optional Separately(Default None)

Plastic Surgery Function:

Optional Separately(Default None)

Lifting Function:

Optional Separately(Default None)

Foot Cutting Function:

Optional Separately(Default None)

Adapt To The Length Of The Material Pipe:

400-600mm

Adapt To The Height Of The Material Pipe:

10mm-45mm

Adapt To The Width Of The Material Pipe:

10mm-28mm

Condition:

New

Highlight:

Dual-channel Tubular Feeder

2s/Pcs Feeding Speed SMT Feeder

OLED Display Screen Rail Vibration Feeder

Payment & Shipping Terms

Minimum Order Quantity

1/PCS

Price

USD+negotiable+pcs

Packaging Details

1600*90*1250mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Yamaha ZS 104mm SMT Feeder for Pick & Place Machines - Japan Origin & Yamaha Brand

Get Best Price

YAMAHA Brand Electric Drive SMT Feeder Car with Multiple Model Compatibility for Feeder Storage and Placement

Get Best Price

YAMAHA SMT Feeder Rack Stainless Steel 2 Floors Design with Universal Wheel and Brake for YS12/10/20/SS Feeder Car

Get Best Price

SMT Feeder Car with High Quality Aluminum Construction 100 Feeder Capacity and Anti-Static Drag Chain for Efficient SMT Production

Get Best Price

Contact Now

Product Description

Tubular Feeder (GS-SAT2112) - Rail Vibration Feeding

The GS-SAT2109/2112 Tubular Feeder is a precision electronic component supply device designed for automated insertion machines. This rail vibration feeding system delivers tube-mounted electronic components one by one at specified intervals through controlled vibration and air blowing mechanisms.

Product Overview

Control Interface

Key Features

Precision component delivery through vibration and air blowing
Timed component supply for automated insertion machines
Rail vibration feeding mechanism for consistent performance
Designed for tube-mounted electronic components
Reliable operation in industrial manufacturing environments

Technical Specifications

Custom Solutions Available

For special material dimensions or unique application requirements, contact our engineering team for consultation. We provide customized solutions and exclusive feeder configurations tailored to your specific manufacturing needs.
