Name: Label Feeder SMT Feeder with Adjustable Feeding Speed 35mm/s 3.5-inch Touchscreen and Feeding Accuracy +0.3mm
Brand: Global Soul Limited
SKU: GS-HQ90
Availability: InStock

Home > Products > SMT Feeder >

Label Feeder SMT Feeder with Adjustable Feeding Speed 35mm/s 3.5-inch Touchscreen and Feeding Accuracy +0.3mm

Adjustable Feeding Speed 35mm/s Label Feeder

3.5-inch Touchscreen SMT Feeder

Feeding Accuracy +0.3mm Component Supply Device

Place of Origin:

China

Brand Name:

Model Number:

GS-HQ90

Document:

Product Brochure PDF

Request A Quote

Label Feeder SMT Feeder with Adjustable Feeding Speed 35mm/s 3.5-inch Touchscreen and Feeding Accuracy +0.3mm

Product Details

Model:

GS-HQ90

Overall Dimensions (length * Width * Height):

930*130/72*390mm( There Are Two Widths: 130mm And 72mm)

Weight:

13/9.5(The 130mm Style Weighs 13KG The 72mm Style Weighs 9.5KG)

Working Voltage:

DC 24V

Gas Source Requirements:

Maximum Current:

Feeding Speed:

Adjustable At 35mm/s

Operation Panel:

3.5-inch Touchscreen

Feeding Accuracy:

+0.3mm

Condition:

New

Highlight:

Adjustable Feeding Speed 35mm/s Label Feeder

3.5-inch Touchscreen SMT Feeder

Feeding Accuracy +0.3mm Component Supply Device

Payment & Shipping Terms

Minimum Order Quantity

1/PCS

Price

USD+negotiable+pcs

Packaging Details

1000*150*90

Delivery Time

1-3 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Yamaha ZS 104mm SMT Feeder for Pick & Place Machines - Japan Origin & Yamaha Brand

Get Best Price

YAMAHA Brand Electric Drive SMT Feeder Car with Multiple Model Compatibility for Feeder Storage and Placement

Get Best Price

YAMAHA SMT Feeder Rack Stainless Steel 2 Floors Design with Universal Wheel and Brake for YS12/10/20/SS Feeder Car

Get Best Price

SMT Feeder Car with High Quality Aluminum Construction 100 Feeder Capacity and Anti-Static Drag Chain for Efficient SMT Production

Get Best Price

Contact Now

Product Description

Label Feeder (GS-HQ90)

The GS-HQ90 Label Feeder is a precision component supply device designed for surface mount technology (SMT) manufacturing processes. It systematically strips rolls of labels at specified intervals and delivers them one by one to the SMT machine, ensuring reliable and efficient production operations.

Tape Specifications & Requirements

Tape Configuration Guidelines

Tape Width: Maximum supported width ≤85mm
Material Spacing: Maintain 2-3mm clearance between materials on all sides (front, back, left, right)
Blank Areas: Reserve approximately 5mm blank space on both sides of the material tape
Items per Row: Limit to 6 items maximum per row (fewer items reduce abnormality risks)
Base Paper Thickness: Optimal thickness: 0.05mm

Operational Benefits

This label feeding system enhances SMT production efficiency by providing consistent, timed label delivery while minimizing jams and errors through proper tape configuration and spacing management.
