H12HSQ Fuji NXT Head Without Backup Pin AA74B19 / AA74B25 Model Number
Product Specifications
| Attribute |
Value |
| Brand Name |
FUJI |
| Product Name |
NXT H12HSQ Head |
| Model Number 1 |
AA74B25 |
| Model Number 2 |
AA74B19 |
| Model Number 3 |
AA74B41 |
| Condition |
Original New/Used Original |
Product Overview
The FUJI Nxt H12HSQ Head is a critical placement head component for FUJI NXT and NXT II SMT pick and place machines, designed to handle a wide range of components with exceptional speed and precision in PCB assembly processes.
Key Features and Benefits
- High-Precision Placement: Ensures accurate component placement, minimizing defects and improving product reliability
- Versatile Component Handling: Accommodates various component sizes and types for flexible production
- High-Speed Performance: Optimized design enables rapid pick and place cycles to maximize output
- Robust Construction: Durable materials ensure long-term reliability with minimal downtime
Maintenance and Performance Optimization
Regular maintenance is essential for optimal performance of the H12HSQ Head, including cleaning, lubrication, and inspection for wear. Key maintenance functions include:
- Periodic nozzle blow cleaning to remove dust accumulation
- Brushing unit to clean nozzle surfaces and reduce vision errors
- Nozzle stuck detection to prevent component damage
- Intelligent Part Sensor (IPS) for automatic nozzle condition monitoring
Common Issues and Solutions
- Pickup Errors: Clean and inspect head, replace worn nozzles
- Placement Errors: Recalibrate sensors and check alignment
- Nozzle Clogs: Perform thorough cleaning or replace nozzle
- Sensor Malfunctions: Clean sensors or replace faulty components
Product Images
Fuji Placement Head H12HSQ
Fuji Placement Head Series
Fuji NXT SMT Head Unit
Frequently Asked Questions
What is the typical lifespan of a FUJI Nxt H12HSQ Head?
With proper maintenance, the H12HSQ Head can last several years depending on usage conditions.
How often should maintenance be performed?
Monthly maintenance is recommended, with more frequent checks for high-volume production environments.
Can I perform repairs myself?
Basic maintenance can be done in-house, but complex repairs should be handled by trained technicians.
What indicates the head needs replacement?
Frequent errors, excessive vibration, noise, or visible damage suggest replacement may be needed.
