FUJI NXT H12HS Head AA74A06 SMT Placement Unit

The Fuji NXT series is renowned in Surface Mount Technology (SMT) for its modularity, flexibility, and high performance. The H12HS placement head delivers exceptional accuracy and speed in component placement, making it a critical component for modern electronic manufacturing.

• High-Speed Placement: Designed for rapid component placement to maximize production throughput
• Exceptional Accuracy: Placement accuracy of +/-0.038 (+/-0.050) mm (3sigma) cpk ≥1
• Versatile Component Handling: Accommodates components from 0402 to 7.5 x 7.5 mm, with heights up to 3.0 mm
• Proven Reliability: Engineered for long-term performance in demanding production environments
• Modular Compatibility: Designed for seamless integration with Fuji NXT series placement machines

• Component Size Range: 0402 to 7.5 x 7.5 mm
• Maximum Component Height: 3.0 mm
• Placement Accuracy: +/-0.038 (+/-0.050) mm (3sigma) cpk ≥1 (Fiducial mark based referencing)
• Machine Compatibility: Fuji NXT series placement machines

• High-Volume Electronics: Ideal for consumer electronics mass production
• Automotive Electronics: Meets stringent quality requirements for automotive manufacturing
• Industrial Equipment: Handles diverse component sizes for industrial applications
