Panasonic SMT Feeder Calibration Jig NM-EJW2A with ≦0.02mm Adjusted Accuracy for CM402/CM602/NPM Feeders and Includes Jig Tape Set

Product Details

Model Number:

NM-EJW2A

Application:

Calibrate Adjust CM402,CM602,NPM Feeder

Dimention:

400*500*1100mm

Power:

100-240V 50/60Hz

Adjusted Accuracy:

≦0.02mm

Calibrated Accuracy:

≦0.05mm

Jig Tape Set:

1set(8mm,12mm,16mm,24mm,32mm,master Jig

Weight:

60kg

Highlight:

Panasonic Feeder Calibration Jig

NPM Feeder Calibration Jig

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+PCS

Packaging Details

400*500*1100mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+PCS+per days

Panasonic Stainless Steel Precision Jig Plate N210005939AA for SMT Feeder Calibration

Get Best Price

Panasonic SMT 16MM Feeder Calibration Jig Plate with Steel Tape for Precision Alignment

Get Best Price

Video

Siemens SMT Feeder Calibration Jig with Visual Inspection 3x8 Configuration for High Precision Calibration

Get Best Price

Video

YAMAHA High-Precision SMT Feeder Calibration Jig with Durable Construction and Wide Compatibility

Get Best Price

Contact Now

Product Description

SMT NPM Panasonic Feeder Calibration Jig CN604/402/NPM NM-EJW2A

Overview

The Panasonic SMT Feeder Calibration Jig NM-EJW2A is engineered to ensure precise calibration of SMT feeders for optimal performance in electronics manufacturing environments.

Usage Process

Setup: Securely position the feeder onto the calibration jig
Calibration Process: Use the jig to adjust feeder alignment and tension settings
Verification: The jig confirms accurate component delivery to the pick-up point
Adjustment: Make necessary corrections for any misalignments or feeding issues

Primary Functions

Accuracy: Ensures precise feeder calibration for accurate component placement on PCBs
Efficiency: Reduces downtime with quick and easy feeder calibration
Quality Control: Maintains consistent production quality by keeping feeders within specified tolerances
Longevity: Extends feeder lifespan by preventing excessive wear through regular calibration

Operational Benefits

Enhanced Productivity: Minimizes errors for smoother production runs and reduced rework
Cost Savings: Lowers production costs by reducing component misplacement and machine stoppages
Consistency: Ensures uniform component placement essential for high-volume manufacturing

The NM-EJW2A calibration jig is an essential tool for maintaining precision and efficiency in SMT production lines. By ensuring proper feeder calibration, it supports consistent quality and optimal performance in electronics manufacturing.

For detailed technical specifications, please refer to the manufacturer's documentation.
