Name: Steel Tool Body SMT Splice Plier Tool with Rubber Handle for Accurate Positioning in SMT Process
Brand: Global Soul Limited
SKU: GSMTL100
Availability: InStock

Home > Products > SMT Splicing Tape >

Steel Tool Body SMT Splice Plier Tool with Rubber Handle for Accurate Positioning in SMT Process

smt splice plier tool

Place of Origin:

China

Brand Name:

Model Number:

GSMTL100

Document:

Product Brochure PDF

Request A Quote

Steel Tool Body SMT Splice Plier Tool with Rubber Handle for Accurate Positioning in SMT Process

Product Details

Brand Name:

Model Number:

GSMTL100

Product Name:

SMT Splice Jig Tool

Dimensions (pc):

5cmx 11.5cm X 2cm

Material:

Steel Tool Body+Rubber Handle

Application:

SMT Process

Customization:

Support

Lead Time:

1-7 Days

Highlight:

smt splice plier tool

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

8cmx 15cm X 5cm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

60g Gram Weight Steel Mesh Wiping Paper with High Efficiency Water Absorption and Anti-Static for SMT Stencil Cleaning

Get Best Price

Video

60g Gram Weight Steel Mesh Wiping Paper with High Efficiency Water Absorption and Anti-Static for SMT Cleaning

Get Best Price

Ultra-Fine Fiber Wiping Roll Cloth 180g with Ultrasonic Edge Sealing and Polyester + Polyamide Composite for Dust-Free Cleaning

Get Best Price

Video

OEM EDM Durable Skin Friendly High Absorption SMT Stencil Clean Roll for SMT Process

Get Best Price

Contact Now

Product Description

GSMTL100 Black SMT Jig Splice Plier Tool For FUJI

The GSMTL100 is a specialized splicing tape feeder jig designed for Fuji equipment, featuring precision holes for accurate tape splicing and cutting. This tool enables precise positioning without requiring extensive operator experience, while its compact design ensures easy portability and storage. Custom logo options are available upon request.

Applications and Versatility

Optimized for FUJI Splice Tape Systems

The GSMTL100 is specifically engineered to integrate seamlessly with FUJI splice tape systems, supporting multiple tape widths for flexible splicing operations without requiring additional tools or adapters.

Cross-Industry Compatibility

Suitable for electronics manufacturing, automotive assembly, and various industries utilizing SMT technology. The tool's universal design makes it effective for splicing SMT carrier tapes across different equipment brands and configurations.

Operational Instructions

Preparing for Splicing: Open the top plate and position the splicing strip on the designated pins.
Cutting the Tape: Lower the top plate to engage the cutting mechanism for a clean, precise cut. Use the eject button to remove excess tape.
Splicing Process: Align the second carrier tape with the guide indentations. Fold the splice tape at the dotted section and press firmly to secure the joint.
Finalizing the Splice: Use the eject button to release the spliced tape, ensuring secure adhesion. Remove protective film as needed to complete the process.

Black SMT Jig Splice Plier Tool For FUJI GSMTL100 | GSSMT, SMT splice tape, SMT splicing machine, SMT splice connectors, SMT splicing equipment, SMT tape splicing tools, SMT splice tool kit, SMT splicing process, SMT splice tool manufacturers, SMT tape splicing technique, SMT splice repair tools, SMT splicing solutions, Automatic SMT splice tools, Manual SMT splice tools, SMT splice tool application, SMT splice tape application, SMT tape jointing tools, High-speed SMT splicing tools, SMT splice tool comparison, SMT splice tape handling, Best SMT splice tools
