Product Description

Bathrive FBT60 Furnace Temperature Tracker

Product Overview

The Bathrive FBT60 is a professional-grade furnace temperature tracker designed for reflow soldering, wave soldering, and various thermal process applications. This advanced instrument provides precise temperature profiling with exceptional battery life and comprehensive data management capabilities.

Key Features

Space-grade 32-bit MCU processor for ultra-strong computing power
Extended 30+ hour battery life with 1000mAh capacity
Stores up to 255 data groups with power-down protection
Modular software design with independent process, product, and furnace libraries
One-click automatic curve optimization with three optimization modes
Millions of temperature curve data models for rapid parameter recommendations
Significantly reduces oven adjustment time through intelligent optimization

Technical Specifications

Instrument Model	Bathrive_FBT60
Number of Channels	6
Instrument Dimensions	222 * 60 * 10 mm
Measurement Precision	±0.5℃
Temperature Resolution	0.1℃
Sampling Speed	100 times/second to 1 hour/time
Storage Capacity	128Mb
Storage Groups	255
Battery Capacity	1000mAh
Start Modes	Explosion-proof high temperature battery temperature, time, button temperature
Stop Modes	Time, button, communication
Operating Temperature	-40°C to 85°C
Temperature Range	-200°C to 1370°C
Thermocouple Type	K Type
Communication Port	USB
Software Languages	Simplified Chinese, Traditional Chinese, English
Software Platforms	Windows XP, 7, 10, 11 (32 or 64-bit systems)

Application Areas

Electronic Manufacturing Semiconductor Photovoltaic Spraying Brazing New Energy Metallurgy Glue Curing (Vertical Furnace) Food Baking
