KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission

KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission

KIC X5 Thermometer

Temperature curve tester

KIC furnace temperature tester

Place of Origin:

China

Brand Name:

KIC

Model Number:

X5

Document:

Product Brochure PDF

Contact Us
Request A Quote
KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission KIC X5 7/9/12 Channel Furnace Temperature Tester with Type K Thermocouple for Real-Time Data Transmission
Product Details
Brand Name:
KIC
Product Name:
KIC Furnace Temperature Tester
Model Number:
X5
Condition:
Original New/Used Original
Highlight:

KIC X5 Thermometer

,

Temperature curve tester

,

KIC furnace temperature tester

Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
USD+negotiable+pcs
Packaging Details
206.0x98.0 x 17.0M
Delivery Time
1-7 days
Payment Terms
T/T
Supply Ability
1+pcs+per days
RELATED PRODUCTS
Good price 00300561-04 00300561S04 00300561 Wrench ASM/SIEMENS SMT Machine Spare Parts online

00300561-04 00300561S04 00300561 Wrench ASM/SIEMENS SMT Machine Spare Parts

Get Best Price
Good price New Original ASM SIEMENS SIPLACE Wrench Model 00200468-02 SMT Machine Spare Parts online

New Original ASM SIEMENS SIPLACE Wrench Model 00200468-02 SMT Machine Spare Parts

Get Best Price
Good price 8*1 NBR 70B O-RING Seal Ring ASM/SIEMENS Compatible New Original/New Compatible online

8*1 NBR 70B O-RING Seal Ring ASM/SIEMENS Compatible New Original/New Compatible

Get Best Price
Good price ASM/SIEMENS SIPLACE 80S#80F Adjustment Potentiometer New Original SMT Machine Spare Parts Regulator Unit online

ASM/SIEMENS SIPLACE 80S#80F Adjustment Potentiometer New Original SMT Machine Spare Parts Regulator Unit

Get Best Price
CONTACT US
Contact Now
Product Description
KIC Furnace Temperature Curve Tester SMT Furnace Temperature Tester KIC X5 Thermometer
Product Overview
The KIC X5 Furnace Temperature Curve Tester represents the next generation of temperature profiling technology, designed to enhance production quality, productivity, and process documentation capabilities in industrial thermal processes.
Key Features
  • Available in 7-channel, 9-channel, and 12-channel configurations with standard Type K thermocouples
  • Enhanced data sampling for precise temperature curve identification and process condition analysis
  • USB connectivity for easy data transfer to computer systems
  • RF version enables real-time wireless data transmission via radio frequency
  • Flexible power options: standard AAA batteries, rechargeable batteries, or USB power
  • Intuitive software with modern graphical interface for complete temperature curve testing
  • Comprehensive process data measurement including slope, soak time, reflow time, and peak temperature
  • PWI (Process Window Index) calculation for objective process window analysis
  • Manual prediction function for immediate process improvement insights
  • Navigator Power™ automatic process optimization technology
  • Standard SPC charting for temperature curve change tracking
Technical Specifications
Accuracy±0.5°C
Resolution0.1°C
Operating Temperature0°C to 85°C
Sampling Frequency0.1 to 10 samples per second
Data Points224,640
PC ConnectionUSB 2.0 (Std-A/Mini-B)
Power RequirementsAAA (3) 7 alkaline batteries or USB 2.0 computer connection
Wireless Receiver Frequency (RF)433.92 MHz
Thermocouple Compatibility7, 9, 12 channels, standard Type K thermocouple
Dimensions (L * W * H mm)7-Channel: 206.0 * 60.0 * 17.0
9-Channel: 206.0 * 75.0 * 17.0
12-Channel: 206.0 * 98.0 * 17.0
Application Areas
  • Electronic Manufacturing
  • Semiconductor Production
  • Photovoltaic Manufacturing
  • Spraying Processes
  • Brazing Operations
  • New Energy Applications
  • Metallurgy
  • Glue Curing (Vertical Furnace)
  • Food Baking
Package Contents
  • Instrument Unit
  • Insulated Box
  • Scissors
  • High Temperature Glue
  • Type K Thermocouple
  • Insulated Gloves
  • Installation Software
  • USB Cable
  • Data Cable
  • Instruction Manual
  • Delivery Report
