BOFA V250 Dual Arm Fume Extraction System For Electronics
In the fast-paced world of electronics manufacturing, ensuring a safe and healthy working environment is paramount. The BOFA Americas V250 Fume Extraction System with Extraction Arm Kit provides an advanced solution for capturing and filtering harmful fumes generated during processes such as hand soldering, potting, and gluing.
System Overview
The BOFA V250 is a dual-arm fume extraction system designed for portability and efficiency in electronics manufacturing environments. This robust system protects operators from potentially harmful airborne contaminants with its advanced filtration capabilities.
Technical Specifications
| Specification |
Value |
| Filtration Efficiency |
99.997% effective HEPA filter |
| Airflow Rate |
106 CFM |
| Noise Level |
Below 54 dBA |
| Weight |
Approximately 22 lbs (10 kg) |
| Dimensions |
Height 420 mm (16.7 inches), Depth 260 mm (10.2 inches), Width 260 mm (10.2 inches) |
Key Features
- Dual Extraction Arms: Designed for simultaneous use by two operators, providing workspace flexibility
- Integrated Speed Control: Adjustable airflow to suit specific applications
- Modular Filter System: Includes pre-filter for larger particles and combined HEPA/gas filter for smaller particulates
- Portable Design: Easily relocated for dynamic factory layouts
Applications
The BOFA V250 is versatile and suitable for various electronics manufacturing applications including hand soldering, PCB rework stations, gluing and potting, and brazing and welding processes.
Benefits
- Health and Safety Compliance: Meets HSE and COSHH regulations for controlling airborne contaminants
- Improved Air Quality: Reduces exposure to harmful fumes for a healthier work environment
- Enhanced Productivity: Operators work more efficiently without unpleasant odors or health risks
- Cost-effective Solution: Modular design allows for easy maintenance and filter replacement
Installation & Maintenance
Installation is straightforward with minimal setup time. The unit includes an installation kit with all necessary components for immediate use. Regular maintenance involves checking filter status and replacement as needed for optimal performance.
Maintenance Guidelines
Conduct weekly visual inspections of filters, replace pre-filters regularly to prolong HEPA filter life, and schedule annual inspections by qualified technicians to comply with safety regulations.
User Experience
Users report high satisfaction with the BOFA V250 due to its performance and reliability. The low noise level (below 54 dBA) allows for comfortable operation in busy environments without causing distractions.
Frequently Asked Questions
- What types of filters does the BOFA V250 use? - The system uses a pre-filter for larger particles and a combined HEPA/gas filter that captures 99.997% of particles at 0.3 microns.
- Is the BOFA V250 portable? - Yes, it is designed to be easily relocated within workspaces as production demands change.
- How often should filters be replaced? - Filters should be checked regularly; pre-filters may need replacement every few weeks, while HEPA filters typically last several months depending on usage.
- Can the BOFA V250 be used in cleanroom environments? - Yes, it features a sealed AC motor suitable for cleanroom applications.
- What is the noise level of the BOFA V250 during operation? - The noise level is below 54 dBA at typical operating speeds, making it suitable for quiet work environments.
