Name: Customized New Horizontal Feeder K Model (GS-AAD2412)
Brand: Global Soul Limited
SKU: GS-AAD2412
Availability: InStock

Home > products > SMT Feeder >

Customized New Horizontal Feeder K Model (GS-AAD2412)

Place of Origin:

China

Brand Name:

Model Number:

GS-AAD2412

Request A Quote

Product Details

Model:

GS-AAD2412

Overall Dimensions (length * Width * Height Unit: Mm):

536*109*140.5mm

Weight:

9KG

Working Voltage:

DC 24V

Gas Source Requirements:

0.5-0.7Mpa

Maximum Current:

1.3A

Feeding Speed:

2s/Pcs

Drive Mode:

Pneumatic

Operation Panel:

0.96-inch TFT Color Screen, 80*160 Pixels

Material Lifting Error:

±0.4mm

Applicable Tape Width:

63-90 Mm

Condition:

New

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

800*300*200mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Customized Horizontal Feeder Model K (GS-AAD2208)

Get Best Price

Customized New Horizontal Feeder K Model (GS-AAD2412)

Get Best Price

Simple Pallet (GS-JAQ2106)

Get Best Price

Pallet Cabinet GS-JAT2501(Single Track)

Get Best Price

86-0755-27678283

Contact Now

Product Description

K Horizontal Feeder (GS-AAD2412)

[Customized Version]

The horizontal feeder is an electronic component supply device that keeps a certain interval and feeds out the horizontal tape-packed electronic components one by one at the prescribed time, shapes them and cuts the lead wires, and supplies them to the insertion machine.

Customized New Horizontal Feeder K Model (GS-AAD2412) 0

Customized New Horizontal Feeder K Model (GS-AAD2412) 1

Applicable to the specifications of braided tape materials

Customized New Horizontal Feeder K Model (GS-AAD2412) 2

Customized New Horizontal Feeder K Model (GS-AAD2412) 3

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
