Name: Tape Adjustment Feeder(GS-RAZ2211)
Brand: Global Soul Limited
SKU: GS-RAZ2211
Availability: InStock

Home > products > SMT Feeder >

Tape Adjustment Feeder(GS-RAZ2211)

Place of Origin:

China

Brand Name:

Model Number:

GS-RAZ2211

Request A Quote

Product Details

Model:

GS-RAZ2211

Weight:

17KG

Working Voltage:

Ac 220V

Gas Source Requirements:

0.5MPa

Maximum Power:

400W(Direct Vibration: 330W)

Feeding Speed:

1.5s/Pcs

Drive Mode:

Electric[Blow Air To Assist In Throwing The Waste Tape]

Operation Panel:

0.96-inch TFT Color Screen 80*160 Pixels

Error In The Length Of The Material Cutting Feet:

±0.1mm

Applicable To The Hole Spacing Of The Tape:

12.7mm/15mm[ Parts Need To Be Replaced]

Applicable Material Body Height:

≤47mm

Applicable Material Pin Diameter:

≤0.8mm

Pin Span:

≤30mm

Function Of Cutting Waste Tape:

By Default, There Is[By Default, There Is None. Circular Materials Cannot Be Bent]

The Number Of Times The Cutter Is Used:

One Million

Condition:

New

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

900*650*120

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days
