Name: Manual Operation SMT Feeder Special feeder for domestic labeling machines
Brand: Global Soul Limited
SKU: GSGCTZFD
Availability: InStock

Home > products > SMT Feeder >

Manual Operation SMT Feeder Special feeder for domestic labeling machines

Domestic Labeling Machines SMT Feeder

Manual Operation SMT Feeder

Place of Origin:

China

Brand Name:

Model Number:

GSGCTZFD

Request A Quote

Manual Operation SMT Feeder Special feeder for domestic labeling machines

Product Details

Material:

Hard Aluminium+ Finishing

Fixed Mode:

Dual-Pins And Rail Positioning, Lock Holder

PC Link:

14 PIN Standard Interface AWG24 Standard Wire

Voltage:

DC 24V

Average Curr:

1 A

Peak Current:

2 A

Vacuum Adsorption:

0.4~0.6MPa Selectable

Software:

Independent Development

Hardware:

Customized Control And Drive Integration Based On ARM

Controller:

Touchpad And Parameters Setting

Working Mode:

Hand/Auto/on-line Mode

Driving Motor:

Stepping Motor

Label Positioning:

Optical Fiber Positioning ,Pulse Compensation

Max Speed:

100mm/s

Feeding Precision:

X Axis Direction ±0.1, Y Axis Direction 0.1 Soil

Applicable Package:

Roll Paper Tape, Packaging Tape

Suitable Type:

Labels. Metal Pieces.Foam.Plastic...

Single/Multiple Platoon:

≤12 Pcs/Row

Label Size:

Single Min :2x2mm,Thickness≥0.02mm

Drive Roller Unit:

Forward Push Stripping

Refuelling Method:

Stop Manual Operation

Waste Recovery:

Selectable

Lack Of Material Alarm:

Alarm And Stop

Drop And Collision Test:

Shell 0.5KG/cm², No Abnormality

Aging Test:

Worked Continuously For 48 Hours Without Any Abnormality

Work Record:

Complete And Consistent

Service Life:

3-5 Years

Wheel Diameter 1:

Inner Diameter D:3 In/ 76.2mm

Wheel Diameter 2:

Outer Diameter D:max 8 In/200mm(other Sizes Customized)

Platform Material:

White Silicone, Black/red/metal Spray Finish Available As Options

Highlight:

Domestic Labeling Machines SMT Feeder

Manual Operation SMT Feeder

Payment & Shipping Terms

Minimum Order Quantity

1 PCS

Price

USD+negotiable+pcs

Packaging Details

570*46*125

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

Original Custom Multi Tube SMT Feeder Automated GSFD-PM-YSGL

Get Best Price

00141290-06 Smt Feeder ASM SIEMENS SIPLACE X FEEDER 8MM

Get Best Price

Asm Siemens Siplace X Feeder Smart Smt Tape Feeder Module 16mm 00141272-06

Get Best Price

Smt Tape Feeder 00141273-06 Asm Siemens Siplace X Feeder Module 24mm

Get Best Price

86-0755-27678283

Contact Now

Product Description

Special feeder for domestic labeling machines

Functional features:
1, designed for domestic labeling machine, compatible with most of the domestic labeling machine, a variety of specifications, can be customized
2, own brand optical sensor, sensitive, precise, up to 20 sense head
3, Feida can automatically run; You can also select the online mode to communicate with the uplink

Manual Operation SMT Feeder Special feeder for domestic labeling machines 0
